Y3 Series Low Voltage and Big Power Three Phase Universal Motor Big

Y3 Series Low Voltage and Big Power Three Phase Universal Motor Big thumbnail-1
Y3 Series Low Voltage and Big Power Three Phase Universal Motor Big photo-1
US$ 10,000 - 16,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
YUTONG
Model Number:
Y3
Type:
Asynchronous Motor
Contact Supplier Request Quote Chat Now
Henan Yutong Electric Motor Shares Company
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name YUTONG
Model Number Y3
Type Asynchronous Motor
Frequency 50Hz
Output Power 355KW-630KW
Protect Feature Totally Enclosed
Phase Three-phase
Certification CCC
AC Voltage Other, 380V
Place of Origin Henan, China
Efficiency IE 3

Y3 series enclosed self fan-cooling squirrel cage rotor three phase induction motor with low voltage and big power, It is improved based on Y2 motor with new material, new crafts and reliable technology. The power

factor and installation way are in line with IEC standard. Y3 series motor is widely used for big power

machines have no special performance requirements, such as machine tools, food machinery, fans,

pumps, compressors, agricultural machinery and other industry.





Main technical performance

Rated voltage: 380V or 660V

Protection class: IP55

Insulation class: F

Cooling method: IC411

Installation way: (table 2) IMB3, IMB35,IMV1





Work Environment

Altitude: less than 1000m

Work temperature: -15°C~+40°C

Relative humidity: less than 85%







type power current A speed eff. power weight
kw 380V 660V rpm factor kg
Y3-400 1-4 450 806 464 1492 96.3 0.88 3100
Y3-400 2-4 500 896 516 1492 96.4 0.88 3200
Y3-400 3-4 560 992 571 1492 96.5 0.89 3400
Y3-400 4-4 630 / 642 1492 96 0.89 3500
Y3-400 1-6 355 661 381 994 96.2 0.82 3200
Y3-400 2-6 400 736 424 994 96.2 0.83 3400
Y3-400 3-6 450 828 477 994 96.4 0.83 3500
Y3-400 4-6 500 918 529 994 95.2 0.83 3600
Y3-400 1-8 315 629 362 745 95.6 0.8 3300
Y3-400 2-8 355 688 396 745 95.6 0.8 3400
Y3-400 3-8 400 775 446 745 95.6 0.8 3500
Y3-400 1-10 250 542 312 595 94.7 0.74 3300
Y3-400 2-10 315 653 376 595 95.1 0.77 3400
Y3-400 3-10 355 736 424 595 95.1 0.77 3500



 Y3 series low voltage and big power three phase universal motor big

Y3 series low voltage and big power three phase universal motor big

Y3 series low voltage and big power three phase universal motor big

Y3 series low voltage and big power three phase universal motor big

Y3 series low voltage and big power three phase universal motor bigY3 series low voltage and big power three phase universal motor big
