Help Center5.8GHz Wifi Mimo Parabolic Antennas TDJ-5800SPE28*2
Related Products
-
High Performance Outdoor Wifi Omni Antenna TQJ-5800AH6US$ 12.00 - 14.50MOQ: 50 Pieces -
5.8G 6dBi Wifi Wlan Fiberglass Antenna Outdoor Omni Antenna N FemaleUS$ 10.23 - 13.38MOQ: 20 Pieces
-
5.8G 10dBi Anttena Outdoor Omni Fiberglass Antenna Wifi Antenna With N Female ConnectorUS$ 15.75 - 18.9MOQ: 10 Pieces
-
5.8G 12dBi WIFI Outdoor OMNI Fiberglass AntennaUS$ 25.00 - 25.00MOQ: 1 Piece
-
5.8G 30dBi Outdoor Directional Point To Point Grid Parabolic Antenna TDJ-5800SPD9US$ 0.01 - 0.1MOQ: 2 Pieces
Application:
1,wifi wlan systems
2,point to point systems
3,mimo systems
Features:
1,broadband frequency
2,High gain and good performance
3,good looking
Specification:
|
Model |
TDJ-5800SPE28×2 |
|
Frequency Range-MHz |
5150~5850 |
|
Bandwidth-MHz |
700 |
|
Gain-dBi |
2×28 |
|
Horizontal Beamwidth-° |
6 |
|
Vertical Beamwidth-° |
4 |
|
F/B Ratio-dB |
≥25 |
|
VSWR |
≤1.5 |
|
Nominal Impedance-Ω |
50 |
|
Polarization |
vertical & Horizontal |
|
Maximum Power-W |
100 |
|
Dimensions-mm |
600×900 |
|
Weight-kg |
3.5 |
|
Rated Wind Velocity-m/s |
60 |
|
Connector |
2×N 2×N female |
|
Mounting Mast Diameter-mm |
Φ35~50 |
MIMO:
MIMO antenna said multiple input multiple output, typically used for IEEE 802.11n, but can also be
used for other 802.11 technology.MIMO techniques can be roughly divided into two categories:
transmit / receive diversity and spatial multiplexing.MIMO antenna is sometimes referred to as
space diversity, because it uses the multiple spatial channels to transmit and receive data ,
using the MIMO technology can increase the channel capacity.
Our company:
Our company are specialized various antennas, and our main products as follow:
1,2.4GHz/ 3.5GHz/ 5.8GHz Wifi/ WLAN/ WiMax/ MIMO antennas
2,VHF/ UHF/ DVB-T/ CDMA/ LTE/ GSM/ GPS/ RFID/ 3G antennas
3,Omni/ Yagi/ Panel/ Grid Parabolic/ Mobile/ Terminal/ Rubber/ Alarm/ Decorative antennas
4,Splitters/ Couplers/ Duplers/ Surge Protectors etc.
