Double girder 32 ton overhead crane is a kind of heavy duty material lifting equipment. It mainly consists of main girder, end beams, trolley travelling mechanism, electric parts and lifting hook. it is widely used in plants, warehouses, materials stocks to lift goods or materials.
1. Parameters - Double girder 32 ton overhead crane
Lifting Weight(t) |
5, 10, 16/3.2, 20/5, 32/5, 50/10 |
75/20, 100/20, 125/32, 160/50, 200/50, 250/50 |
300/40, 350/75, 450/80 |
|
Span(m) |
10.5-31.5 |
13.5-31.5 |
17-22 |
|
|
Max. Lifting Height |
Main hook |
20 |
22 |
24 |
Auxiliary |
22 |
22 |
32 |
|
Steel Track Recommended |
43kg/m or QU70 |
QU100 |
QU120 |
|
Working duty |
A3- A7 |
|||
Voltage supply |
380v, 50hz, 3-phase or as your requirements |
|||
Working temperature |
-10℃-- 40℃ |
|||
2. Drawing - Double girder 32 ton overhead crane
3. Control mode - Double girder 32 ton overhead crane
Our Services |
|
Pre-Sales Service After-Sales Service * Inquiry and consulting support. * One year warranty. * Drawings support. * Engineers available overseas. * Technical support. * Installation training. * Commissioning. * Using training. * View our Factory. * Maintenance training. |
1. What should I provide when inquiry? |
A: Lift capacity B: Span C: Lift height D: Power source E: Control mode F: Other requirements The more detailed, the better! |
2. Are the products customized? |
The cranes are customized according to your using condition and requirements |
3. How to install? |
|
A: Installation and use manual. B: Do the installation training for you. C: Engineers available to service machinery overseas. |
4. Crane failure |
The accessories are free in the period of warranty if it is the quality problems |
