Help CenterPine Flange H20 Beams
US$ 350 - 400
MOQ: 50 Cubic Meters
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
yeluwood
Model Number:
lvl
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
SGS Lvl Scaffolding Plank H20 Wood Beam Pine Hardwood Birch for ConstructionUS$ 350 - 400MOQ: 50 Cubic Meters -
Wall Formwork H20 Beam,H20 Beam for Africa MarketUS$ 350 - 400MOQ: 50 Cubic Meters
-
Standard WBP Pine H20 Beam for ConstructionUS$ 350 - 400MOQ: 50 Cubic Meters
-
Pine H16 Beam(best Quality)US$ 350 - 400MOQ: 50 Cubic Meters
-
H20 Pine Lumber Wood I Beam With End TreatmentUS$ 350 - 400MOQ: 50 Cubic Meters
Place of Origin
Shandong, China
Brand Name
yeluwood
Model Number
lvl
Usage
Outdoor
Grade
First-Class
Main Material
Pine
Formaldehyde Emission Standards
E0
Plywood Type
18-Ply Boards
Description:
1).Flange: Solid sawn spruce lumber, 80x40mm
2).Web: OSB or Spruce 3-ply rediate pine plywood (pine is imported from New Zealand.)
3).Thickness of Web: 27mm/ (+/ 1mm) , or as requested.
4).Height : 200mm
5).Glue : Phenolic WBP(can be boiled for 72 hours)
6).Painting : Yellow Waterproof or as requested.
7).Length : 1.8m,2m,3m, up to 11.8m, or as requested.
- Protection cap possible up to 9m-over 9 m only cut straight
- Rounding with sealing possible up to 9m-over 9m only cut straight
- Labor force Vk=23.9KN
- Contact resistance Rb,k=47.8KN
- Bending moment Mk = 10.9 KNm
- Rigidity I Ei=450 KNm2
- Weight: 4.8kg/m
Caution:
- Wooden formwork beams are only to be used in an upright position.
- In addition, they are to be secured against tipping according to static requirements
- Every item must be inspected by the installation firm and may only be used if in perfect condition.
- Damaged or formwork girders weakened by decay are not be used.
