<1>I-Beams For Concrete Formwork:
1> if used abide by the illustrations strictly, it can be reused many times.
2> reducing the cost greatly and avoiding the disadvantage:restily and erosive of iron mould.
3>.solve the problems of leaking and rough surface during constructing process
4> realizing a higher economic profies.
5> .new technology and materials are being introduced and popularized continuously for construction...........
<2>I-Beams
Flange |
Made of carefully selected spruce, Radiata pine. |
Finger-jointed, high grade, solid wood | |
Finger-jointed and glueing according to DIN 68140-1 | |
Web |
3-plywood or plywood |
Wood types |
Spruce, Pine, a mixture of wood species permitted |
Glueing |
(PRF) Finger-joints between flange and webs pursuant to approval notice Z-9.1-146 |
Wood Moisture |
less than 12% at the time of delivery |
Surface Protection |
The complete beam is waterproofed using a water-repellent color glaze |
Weight |
about 5kg/m |
Standard lengths |
2.45 / 2.90 / 3.30 / 3.90 / 4.90 / 5.90 m (Max.length:6.00m) |
Machanical Specification |
Modulus of elasticity : E 11,000 N/mm2 |
Shear modulus : G 600 N/mm2 | |
Packing |
The packages are delivered suitable for the construction site and protected by |
integrated supporting timber. |
