Help CenterH20 Beam Formwork Wall System
Related Products
-
Low Lvl Beam Price of Pine H20 Beams for ConstructionUS$ 6.8 - 7MOQ: 5 Cubic Meters -
Similar With Peri Formwork Wood Beam H20US$ 6.8 - 7MOQ: 5 Cubic Meters
-
H20 Shuttering Formwork BeamUS$ 6.8 - 7MOQ: 5 Cubic Meters
-
Best Quality Beam Pine Lvl Joists H20US$ 6.8 - 7MOQ: 5 Cubic Meters
-
Slab Formwork System Timber Beam H20/Timber Beam H20 For FormworkUS$ 6.8 - 7MOQ: 5 Cubic Meters
Beam Wall Construction Formwork is the basic wall formwork mainly consisted by H20 timber beam and steel waling with plywood. It can be easily shaped to different sizes and shapes according to specific projects, even to round or curved walls with different diameter by shaping wood. Meanwhile, it is efficient and cost-effective, thus is widely used in the sites across the world.
Feature
* Ready to use construction formwork after pre-assembly
* Efficient and time-saving especially for large area walls where request for repeated castings
* Can be shaped into any size and shape according to different project structures
* Can meet different fresh concrete pressure by spacing the timbers and walings
* Can produce fair-faced concrete finishing
* Can be transfer into adjustable column formwork according to TECON specially arranged solution
Technical Specification
* Basic unit sizes (width*height): 1.0m*3.0/3.6/4m, 1.25m*3.0/3.6/4m, 1.5m*3.0/3.6/4m, 2.0m*3.0/3.6/4m, 2.0m*3.0/3.6/4m, 3.0m*3.0/3.6/4m, 4.0m*3.0/3.6/4m, 5.0m*3.0/3.6/4m, 6.0m*3.0/3.6/4m
* Or any customized unit sizes according to structural drawings
* Up to 6m wall height with just one pouring
* Main components: 18mm brown film plywood; H20 timber beam(EN); #12 steel waling
