H20 timber beams SPECIFICATION:
1)Materail:New Zealand Radiate Pine
2)Flange: 80*40mm(LVL Structure)
3)Web: 27mm (Plywood or LVB Structure)
4)Weight/: 5.00kg-5.20kg/meter
5)Length avaible:Max 12meter
6)Quality: SGS test report according to EN13377:2002
7)Surface finishing: waterproof yellow painting or other color as the customers request
8)Package:Pallets on the bottom,and Steel band for strength
9)GLUE:WBP/MUF
10)Price advantage: 20-30% cheaper than Austria based on same quality
Product Name |
|
Height |
200mm |
Flange |
Wide*Thickness=80mm*40mm |
Spruce, Pine, a mixture of wood species permitted | |
Web |
Thickness:27-30mm |
3-plywood or plywood | |
Surface Protection |
The complete beam is waterproofed using a water-repellent color glaze |
Weight |
4.6-5.2kg |
Standard Lengths |
2.45m,2.65m,2.9m,3.3m,3.6m,3.9m,4.5m,4.9m,5.9m, (Max.length:6.00m) |
Shear Force |
q=11KN |
Permissible Bending Moment |
m=5.0KN*M |
Package |
Customized Package,or In Bulk |
Used for |
Slab Formwork System,Vertical Formwork(Wall,Column,Hydraulic Climbing etc.), Adjustable Arced Formwork etc |
production
ITEM |
Working capacity |
EN request |
SGS test |
maximum bending resistance |
5KN.M |
10.9KN.M |
16.2KN.M |
maximum shearing resistance |
11KN |
23.9KN |
30.8KN |
maximum bearing resistance |
22KN |
47.8KN |
53.2KN |
Trade Terms:
1.) MOQ: 1*20G
2) Payment terms: T/T with 30% deposit in advance or L/C at sight
3) Delivery time: 15~20 days after getting your deposit
4) Packing: seaworthy pallets packing
