Telescoping Glass Door
GTD Automatic Telescoping Glass Door Big Size
Brand Name: Maxdor
Model Number:GTD
Door Type : telescoping glass door
Door Material: Glass , aluminum frame
Application type:stores,banks,hotel, Hospitals, restaurants,conference center,exhibition building
Delivery Detail: 10-15 days after receiving customers payment
Packaging Detail: Carton packing
*Can choose ES200 control system or GT150 (GT300 ) control system
Automatic Telescopic sliding door includes Single open or double open.
Characteristic
*Self programming electronics to automatically set door operation on installation.
*Safety Functions,If the door leaves are hindered when opening, they are immediately stopped.
*The position of the obstacle is stored and will be slowly approached during the next door movement.
Dimensions | |
Clear passage width |
LW 1800-4000mm |
Maximum opening width |
8000mm |
Door leaf weight, max |
4×50kg |
Clear passage height |
LH 2100×3000mm |
Fixed side screens |
Optional |
Telescopic Door Technical data
Opening and closing force, adjustable , max |
150N |
Multiple data adjustable | |
Power supply data |
230V,50/60Hz |
Power consumption |
360W |
Power consumption, average |
30W |
External power supply |
24V, 2A |
Standard Components |
|
1. Motor Drive Unit 2. Transformer 3. Control module 4. Electronic lock 5. Belt connection 6. Belt carrying wheel 7. Locating wheel 8. Mute rubber
|
Optional Accessory |
|
10. Battery pack 11. Cover 220mm 12. Electric mechanical lock or Manual unlocking device 13. Safe barrier or BEA Eagle six safe sensor(with radar curtain) |
