Help CenterMaxdor GTW Semi-circle Aluminium Automatic Curved Sliding Door
Related Products
-
Aluminium Automatic Full Circle Curved Sliding DoorUS$ 800.00 - 1000.00MOQ: 1 Set -
Maxdor GTW Automatic Curved Doors Lock SystemUS$ 800.00 - 1000.00MOQ: 1 Set
-
Hign Quality Automatic Arc Door For CommercialUS$ 800.00 - 1000.00MOQ: 1 Set
-
Aluminum Glass Curved Sliding DoorUS$ 1000.00 - 1000.00MOQ: 1 Piece
-
Commercial Curved Sliding Door for MallUS$ 1000.00 - 1000.00MOQ: 1 Piece
Brand Name: Maxdor
Model Number:GTC
Door Type : curved sliding doors
Door Material: Glass , aluminum frame
Application type:stores,banks,hotel, Hospitals, restaurants,conference center,exhibition building
Delivery Detail: 10-15 days after receiving customers payment
Packaging Detail: Carton packing
*Can choose ES200 control system or GT150 (GT300 ) control system
Automatic curved sliding door includes semi-circle ,full circle or segment version, concave or convex version, with fixed panel or not.
Characteristic
*Safety Functions,If the door leaves are hindered when opening, they are immediately stopped.
*Emergency opening in case of power failure / Fail-safe
Obstacle detection with automatic return mechanism
*Self monitoring light barriers ,slow speed search for obstruction
Dimensions | |
|
Technical data
|
Door leaf weight (maxmum).100kg Opening speed per door leaf, adjustable 100-600mm/s Opening speed per door leaf, adjustable 100-655mm/s Opening and closing force, adjustable Maximum force on contact with an obstruction 150N Power input, max.360W Power supply data 220V/50-60Hz External power supply 24V/2.5A |
Standard Components |
|
1.Mini Drive Unit (2-5) 2.Transformer 3.Motor 4.Decoder 5.Basic control module 6.Curver Track 7. Belt tensioning device 8.Carrier 9.Return pulley 10.End stop 11.Belt connection 12. Remote switch(or Functional switch)
|
Optional Accessory |
|
13.Electric mechanical lock 14. Battery pack 15.Cover 16. Glass clamping rail 17. Light barrier |
Maxdor GTC Automatic commercial curved glass doors
- R&D department will develop and improve new products for the guests .
- Our products provide 2 years warranty
*All product through CE ,ROHS ,FCC certification, strict quality supervision.
Q1:Do you have a factory?
A: Yes, we are the automatic doors manufacturer, mainly engaged in automatic door design, sales, construction and after-sales service for nearly 10 years; therefore, for any needed in auto door, just contact us.
Q2:What about the payment?
A: 30% deposit should be paid before the production,70% balance payed before shipment .
T/T, L/C(Irrevocable L/C at sight),west union.
Q3:What about your delivery time? can we receive our goods on time?
A: Usually 10-15 days after you confirm the sample's quality. Exact delivery time depends on exact quantity. We regard clients' time as gold, so we'll do our best to deliver goods on time.
Q4:Can you make Door to Door service ?
A: Yes. We can offer Door to Door service to help you save time of shipping. We have discount with our cooperating shipping company. So it can save your time and money.
Q5:What about your samples?
A:We can provide the sample in 4-5days, and per style per sample need cost and the expess shipping fee, but we will return sample free if you set the order. Also welcome to our company to have consult.
