Sling Door System
Universal Remote Sling Door System China Door For Physical Disability
ADA Compliance: The Americans with Disabilities Act guarantees that handicapped people can enter any building with little effort, in spite of their physical disability. Many businesses had to install ADA-compliant automatic doors to avoid breaking the law.
PRODUCT PARAMETER
| Technical Product data | ||
| GT150 door parameters with single motor | ||
| Leaf sliding door | Single-leaf sliding door | Double-leaf sliding door |
| -Clear passage width LW | 700-3000mm | 800-3000mm |
| -Door leaf weight, Max | 1 x 200kg | 2 x 160kg |
| Technical data | ||
| Structural height | 200mm | |
| Structural depth | 165mm | |
| Motor | 60V 100W brush Motor | |
| Opening &closing force, max | 150N | |
| Opening speed | 300-700mm/s | |
| Closing speed | 200-500mm/s | |
| Pausing time | 0-10/30s | |
| Pow consumption | 150W | |
| Power supply date | 230V,50Hz | |
| Protection rating | IP23 | |
| Ambient temperature | 15°…+500° | |
| Standard Components | ||
| 1.Motor Drive Unit | 2. Track 4.2M | 3.Control module |
| 4.BEDIS control panel | 5. Belt connection | 6. Belt carrying wheel |
| 7. Locating wheel | 8. Mute rubber | 9.2PCS sensors |
| Optional Accessry | ||
| 9. Safe barrier | 10. Cover 220mm | 11.Manual unlocking device |
| 12. Electric mechanical lock with template | 13. Battery pack with template | 14.BEA Eagle six safe sensor(with radar curtain) |
PRODUCT FEATURES
1. Two wire connect, installation easy, function advance.
2.GT150 With latest module, capable of achieving complex functional operation.
3.Germany Dunker Motor with 60v 100w brush moto
PACKAGE & SHIPPMENT
1.Carton packing
2. 10-15 days upon receive the payme
