Specifications
1, unscrambler machine2, 5000 BPH
3, automatic controlling system
4, good quality stainless steel made
LP series PET bottle unscrambler machine is suitable for unscrambling disordered plastic bottles.
Working principle:
The disordered bottles are carried into the storing section of the machine, with the help of the pushing force of the rotating disk, the bottles enter their position. Then the turning-bottle device and the air-flow make the bottle-mouth upward, at last bottles are discharged to the next process by air-transfer-erring conveying system. The machine adopts PLC system. Its frequency control system can adjust its production capacity easily. By this machine, the broken bottles can be avoided.
Model |
LP-12 |
Capacity |
5000 bottles per hour |
Amount of working position |
12 |
Air source |
Pressure 0.7MPa,air consumption,1500 L/min |
Power |
380V,50Hz |
Main motor power |
1.5KW |
Bottle size |
Diameter 50-90 mm,height 65-290 mm |
Lifting device power |
0.75KW |
Dimension |
1700(D) 2000(H) |
Total weight |
2000Kg |
A: LP series automatic bottle unscrambling machine
B: Water treatment system
C: PET bottle blowing machine system
D: Automatic bottled beverage filling 3-in-1 machine
E: Automatic bottle body dryer
F: Automatic labeling machine
G: Automatic date printer
H: Automatic PE film bottle packing machine
I: Filled bottle conveying system
No |
Model |
LP-14 |
LP-16 |
LP-18 |
1 |
Amount of working position |
14 |
16 |
18 |
2 |
Capacity |
8000 BPH |
10000 BPH |
15000 BPH |
3 |
Air source |
Pressure 0.7MPa,air consumption,2000 L/min |
||
4 |
Power |
380V,50Hz |
||
5 |
Bottle size |
Bottle diameter 50-96,bottle height 165-310 |
||
5 |
Main motor power |
1.5 KW |
2.5 KW |
3.0 KW |
8 |
Dimension |
2240(D) 2200(H) |
2240(D) 2200(H) |
2640(D) 2300(H) |
9 |
Total weight |
3200Kg |
3500Kg |
4000Kg |
