Purlin Making Machine
Finished product:
The PLC controller is the "CPU" of forming machine. We choose Mitsubishi PLC from Japan.
With touch screen mode, let your workers enjoy the easy operation;
With auto working mode, let your workers free their hands!
Inside of PLC Controller for reference
Why choose this machine?
1.Certificate: ISO 9001, CE,
2. Lifetime services
3. Cr12 mould steel rollers; 82mm diameter solid steel shaft. Lifetime>10years.
4. Introduced Mitsubishi PLC with touch screen to machine controll system.
5. Heat treatment:Cutting blade. Quenched treatment: Cr12 mould steel cutter
6.Technician overseas installing and training available
1. Purlin Making Machine Main Technical Parameters:
Item |
Specification |
|
|
Material |
Type |
Galvanized coils |
Thickness(mm) |
1.5-3 |
|
Yield strength(mpa) |
235 |
|
Roller material |
Cr12 mould steel |
|
Forming speed(m/min) |
10-15 |
|
Output speed(m/min) |
6-8 |
|
Speed adjusting mode |
AC Frequency |
|
Size |
Decelerating motor + Chain drive |
|
Cutting mode |
Hydraulic cutting |
|
Cutter material |
Cr12 mould steel |
|
Length measurement |
Encoder |
|
Control mode |
Mitsubishi PLC |
|
Operating mode |
Button + Mitsubishi Touch screen |
|
Main motor power(kw) |
15KW |
|
Hydraulic motor |
5.5KW |
|
3. Purlin Making Machine Process flow:
Decoiler -- Feeding & Guiding – Leveling--Roll forming---Hydraulic Cutting – product to run out table
About us
We are professional in making roll forming machines since 2003.
Company occupies 6650, in which 5650 for workshops.
1. Capacity: 12-15 sets/month
2. Delivery: in only 5-8 weeks for urgent order
3. Have our own tool center. 12 sets CNC machines to process machine rollers.
4. Zhongyuan is a "All-in-house source"
--from raw material to the final high-precision forming machine. We have our precise tooling center.
5. Over 15 years engineers to design and make your machines.
Lifetime services;
Technician can be sent to your factory to install the machine and train your workers
Get Free:
"Send" below to get profile drawing & design technical support by our 15 year experience technicians FOR FREE!
