Sale Roofing Machines From China
- 20 Set / Sets per Month
- Shanghai/Ningbo
- T/T
- 4 axis CNC Milling Machine To Router 2d 3d Woodworking Craft
- Photovoltaic solar panels recycling plant
- Solar panel recycling machine with high efficiency
- Micro wire mesh weaving machine from LANYING wire mesh weaving machine
- LANYING woven wire mesh machines - stainless steel wire mesh weaving machines
- Jotun JT-SDJ Industrial Automatic Metal Sheet Surface Polishing Machine
Product Details
Place of Origin: | Zhejiang, China | Brand Name: | Zhongyuan | Model Number: | ZY |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Sale Roofing Machines From China
Machine details
Hydraulic hose bear W.P 38mpA / B.P 112MPa.
Machine details
4 emergency switches in front and back of machine.
Wire is Double protected.
Machine details
Wire is fixed tidiness
Machine details
Gears with protector
Warnning lables on protector
Keys to fix gears and shafts
Machine details
Keys to fix rollers and shafts(72mm)
rollers and shafts are solid steel
16mm thickness wall
Improved USER EXPERIENCE
We choose Mitsubishi PLC from Japan.
With touch screen mode, let your workers enjoy the easy operation;
With auto working mode, let your workers free their hands!
Why choose this roofing machine?
1. Certificate: ISO 9001, CE,
2. Lifetime services
3. Roller cover with 0.05mm chrome; 72mm diameter solid steel shaft. Lifetime>10years.
4. Introduced Mitsubishi PLC with touch screen to machine controll system.
5. One worker operation (minimum)
7. Cr12 mould steel cutter with quenched treatment. Cutting blade with heat treatment.
8. Product cut-to-length.
9.Technician overseas installing and training available
1. Parameters
Item | Specification | |
Material | Type | Pre-painted steel coil & galvanized coils |
Thickness (mm) | 0.4-0.7 | |
Yield strength (mpa) | 235-345 | |
Roller material | 45#Chrome steel | |
Forming speed(m/min) | About 20-25 | |
Speed adjusting mode | AC Frequency | |
Cutting mode | Hydraulic cutting | |
Cutter material | Cr12 mold steel | |
Length measurement | Encoder | |
Control mode | Mitsubishi PLC | |
Operating mode | Button + Mitsubishi Touch screen | |
Main motor power (kw) | 7.5 kw (Depend on final design) | |
Hydraulic station power | 2.2 kw (Depend on final design) |
2. Process flow:
Decoiler -- Feeding & Guiding -- Roll forming---Hydraulic Cutting – product to run out table
3. Components
Decoiler (manual/ hydraulic decoiler for option) | 1set |
Feeding & guiding device | 1set |
Pre-cutting device | for option |
Main roll forming machine | 1set |
Hydraulic cutting system | 1set |
Controlling system | 1set |
Run out table (auto. Stacker for option) | 1.5m/ pc, 2 pcs |
About us
We are professional in making roll forming machines since 2003.
Company occupies 6650, in which 5650 for workshops.
1. Capacity: 12-15 sets/month
2. Delivery: in only 5-8 weeks for urgent order
3. Have our own tool center. 12 sets CNC machines to process machine rollers.
4. Zhongyuan is a "All-in-house source"
--from raw material to the final high-precision forming machine. We have our precise tooling center.
5. Over 15 years engineers to design and make your machines.
1) Q: Are you manufacturer or trading company?
A: We are manufacturer and trading company .
2) Q: Do you provide installing and training overseas?
A: Overseas machine install and worker training services are optional.
3) Q: How is your after sales support?
A: We provide technical support on line as well as overseas services by skillful technicians.
4) Q: How does your factory do regarding quality control?
A: There is no tolerance regarding quality control. Quality control complies with ISO9001. Every machine has to past testing running before it's packed for shipment.
5) How can I trust you that machines pasted testing running before shipping?
A: 1) We record the testing video for your reference. Or,
2) We welcome your visit us and test machine by yourself in our factory.
6) Q: Do you have this roofing machine in stock?
A: No, machine is made to order.
7) Q: Will you deliver the right goods as ordered? How can I trust you?
A: Yes, we will. We are ALIBAB’s Gold supplier with BV assessment (Audit report can be provided).
We joined Alibaba trade assurance. With Trade Assurance, you’re covered for On-time shipment and Pre-shipment product quality (Optional).
8) What should I provide if I`d love to customized my machine?
A: To customize machine, we`d love to know:
1. Profile drawing
2. Raw material: the width(1250mm?), thickness(0.3-0.7mm?), and yield strength of steel coil.
3. Voltage: designed per your requirement
4. Configuration requirement: Hydraulic or manual decoiler/ stacker
Have no idea about them?
We will be glad to recommend machines ----Just let us know your country!
Lifetime services;
Technician can be sent to your factory to install the machine and train your workers.
Get Free:
"Send" below to get profile drawing & design technical support by our 15 year experience technicians FOR FREE!
