Steel Floor Deck Roll Forming Machine with Auto Stacker
Brief introduction
1. Designed by 15 years experienced R&D members with lifetime services.
2. Introduced Mitsubishi PLC with touch screen.
3. Need only one worker (minimum) to operate
4. Roller cover with 0.05mm chrome, ensure lifetime>10years
5. Cr12 mould steel cutter with quenched treatment. Blade with heat treatment.
6. Product cut-to-length.
7. 82mm diameter solid steel shaft
Machine was designed by 15 years experienced R&D members with lifetime services
Certificate: ISO 9001, CE,
Cr12 mould steel cutter with quenched treatment.
Improved structure, more stable cutting performance.
Steel Floor Deck Roll Forming Machine with Auto Stacker
1. Parameters
Item |
Specification |
|
|
Material |
Type |
Pre-painted steel coil & galvanized coils |
Thickness |
0.8-1.2mm |
|
Yield strength |
235-345Mpa |
|
Roller material |
45#Chrome steel plate with hard chrome |
|
Forming speed |
15-20m/min |
|
Speed adjusting mode |
AC Frequency |
|
Roller drive |
Decelerating motor + Chain drive |
|
Cutting mode |
Hydraulic cutting |
|
Cutter material |
Cr12 mould steel |
|
Length measurement |
Encoder |
|
Control mode |
Mitsubishi PLC |
|
Operating mode |
Button + Mitsubishi Touch screen |
|
Main motor power |
11x2KW |
|
Total power |
27.5KW |
|
2. Components
3. Process flow:
Decoiler -- Feeding & Guiding -- Roll forming-- Hydraulic Cutting - Product to Auto Stacker
Rollers material: No.45 Forged Steel with Hard Chrome
Shafts for rollers: Grand twice, 82mm diameter solid steel
PLC Controller for machine controller system
Operation mode: button + Touch screen
Inside of PLC Controller for reference
About us
1. Customize roll forming machines since 2003.
2. Capacity: 12-15 sets/month
3. Delivery: in only 5-8 weeks for urgent order
4. Company occupies 6650, in which 5650 for workshops
5. Have our own tool center. 12 sets CNC machines.
6. Technician can be sent to your factory to install the machine and train your workers
7. Zhongyuan is a "All-in-house source"
--from raw material to the final high-precision forming machine. We have our precise tooling center.
Factory Location
Lifetime services;
Technician can be sent to your factory to install the machine and train your workers
Please feel free to contact us for more information!
