Help Center30kW High Voltage Power Supply for Image Intensifier
Related Products
-
Newheek TH-30C HV Power Supply for X-ray DeviceUS$ 1,000 - 2,000MOQ: 1 Piece -
5761HDP1P5 Image Intensifier High Voltage Power SupplyUS$ 1,000 - 2,000MOQ: 1 Piece
-
CCD Camera for Diagnostic X-ray Quality ChoiceUS$ 600 - 1,200MOQ: 1 Piece
-
Image Signal Processor for X-ray MachineUS$ 500 - 1,000MOQ: 1 Piece
-
Medical High Scan Imaging MonitorUS$ 800 - 2,000MOQ: 1 Set
OUTPUT HIGH VOLTAGES | |
G1 |
10-350V |
G2 |
0.2-2KV |
G3 |
2-20KV |
G4 |
2.5-3KV |
G5 |
30KV |
PINOUT TP TEST POINTS | |
TP1 |
G1/100 |
TP2 |
G2/1000 |
TP3 |
G3/10000 |
TP4 |
G4/1000 |
TP5 |
G5/10000 |
TPE |
( I getter/10μA )× 1 volt |
TPPC |
( I PC /10nA)× 1 volt |
PIN OF INPUT CONNECTOR | |
4,5,7,8 |
0V |
1 |
0V |
2 |
RXD input |
3 |
TXD output |
9 |
DTR output |
10 |
CTS input |
6 |
Control Voltage 2 |
11 |
Do not use |
12 |
( I PU/10nA) × 1 volt |
13 |
Control Voltage 3 |
14 |
Control Voltage 1 |
15 |
Power input+21.6-26.4V, 350mA DC max |
3. Configuration
High Voltage Power Supply: 1 Piece
4. Packing
* Waterproof carton
* Carton size: 22.5cm*22.5cm* 20cm
* Gross weight: 2.1kg; Net weight: 1.68kg
5. Delivery
* We promise delivery the product within 3 days after receiving the payment.
* We promise to choose the safest and most ecomonic express.
* DHL, UPS, TNT, EMS etc express can be chosen at random.
