Help CenterMINI Promotion New Design HD200 IR IP Cctv Camera
Related Products
-
Cheap Full D1 H.264 16CH NVR,P2P, Cloud Service, 4CH D1 Play Back OnlyUS$ 30 - 40MOQ: 1 Piece -
HD 2MP IP Outdoor Camera, Hot Sale Onvif ip Camera, HD IP CameraNegotiableMOQ: 1 Piece
-
Sony Effio-e 700TVL Ccd Camera,sony Ccd CameraUS$ 30 - 50MOQ: 1 Piece
-
1.0MP Promotion Waterpoof HD IP Camera, ONVIF, 3G, Hot PromotionUS$ 30 - 50MOQ: 1 Piece
-
1.0 Megapixel Progressive Scan Digital CMOS HD CCTV Dome IP Camera for ImportNegotiableMOQ: 1 Piece
Specifications
HD 200 ONVIF IP camera
IP66 waterproof iR IP camera
4MMLens
60M ir distance
twoyears warrantee with good quality
Thanks dvr applies the leading SOC technology, and standard H.264
including, with high-definition image and more stable system.This model has powerful function and user friendly GUI. Support cloud service, operate easily, and suitable for home, shop, small and medium civil security.
Main Features:
*Latest cloud service, patent NAT (Network Address Translation) technology, realize the remote access easily
* Support PC and Smartphone playback
* The unique data storage technology, which can record the data of 1 sec before power failure
* Support composite streaming and video streaming encoding. Under the composite steaming encoding,
video and audio can be encoded synchronously
* Support VGA, BNC and HDMI output
* High definition VGA display, 800*600, 1024*768, 1280*1024
* Support digital zoom in preview and playback
* Support different PTZ protocols, support present tour function
* Activates event recording automatically when alarm is triggered, and send alerts with images to designated emails
Specifications:
Model |
AK-508HD200 |
|
System |
GUI: |
Graphic User Interface(OSD Menu) |
Operation system: |
Linux(embedded) |
|
Multiplex Operation: |
Pentaplex : Preview, record, playback, backup, network |
|
Video/ Audio input |
password security : |
Multi-user management operation |
Analog video input: |
4CH,BNC, 1.0p-p, 75Ω, |
|
Audio input: |
1CH, RCA, 2.0Vp-p,600kΩ |
|
Video/Audio output |
HDMI Output: |
support |
VGA output: |
1CH, resolution: 800*600, 1024*768,1280*1024 |
|
Display: |
1ch / 16ch optional |
|
Video standard: |
PAL/NTSC |
|
CVBS Output: |
1CH,BNC, (1.0Vp-p,75Ω) Resolution: PAL (704*576), NTSC(704*480) |
|
Audio output: |
1CH, RCA, (Linear electrical level, 600Ω) |
|
Video/Audio encoding parameters |
Video compression: |
H.264 |
Display frame rate: |
PAL: 100fps (4 x 25 fps)NTSC: 120fps (4 x 30 fps) |
|
Record frame rate: |
PAL: 100 fps(4 x 25 fps) NTSC:120 fps(4 x 30 fps) |
|
video coding resolution: |
4x D1(704X576) |
|
video frame rate: |
1-25FPS |
|
video bit rate: |
changeable and fixed bit rate(optional) |
|
Stream type: |
composite/ video |
|
Audio compression: |
ADPCM |
|
Recording Mode: |
Support normal / timer / alarm / motion detection recording |
|
search video files : |
By time period / channel / video type |
|
Audio bit rate: |
8-32kbps |
|
Dual steaming: |
support |
|
Mobile phone monitoring: |
Android / iphone / blackberry / windows / symbian |
|
Recording resolution: |
Recording:4ch D1 Playback: 4ch D1 |
|
Synchronous Playback: |
4ch |
|
Hard Disk Driver |
Type: |
1 SATA interface |
capacity: |
Maximum 3TB HDD |
|
recording type(Audio) : |
audio and video recording simultaneously |
|
remote control /mouse |
support |
|
Network: |
Support IE/PPP0E/DDNS, DHCP,DDNS,PPPoE, IE view, and CMS central control |
|
NAT |
Support |
|
Network interface: |
1 RJ45 10M/100M, adaptive Ethernet interfaces |
|
Serial interface: |
1 standard RS-485 serial interface |
|
interface: |
2, USB 2.0 |
|
software upgrade: |
Support USB/ network upgrade |
|
Others |
Power supply: |
DC12V@2A |
consumption(without HDD) |
≤15W (Without HDD) |
|
Working Temperature: |
-10°C--+55°C |
|
working Humidity: |
10%--90% |
|
