Home > Security & Protection > Surveillance, Control & Protection > CCTV Camera > Cheap Full D1 H.264 16CH NVR,P2P, Cloud Service, 4CH D1 Play Back Only

Cheap Full D1 H.264 16CH NVR,P2P, Cloud Service, 4CH D1 Play Back Only

Cheap Full D1 H.264 16CH NVR,P2P, Cloud Service, 4CH D1 Play Back Only thumbnail-1
Cheap Full D1 H.264 16CH NVR,P2P, Cloud Service, 4CH D1 Play Back Only photo-1
US$ 30 - 40 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Thanks
Model Number:
AK-7216N
Contact Supplier Request Quote Chat Now
Guangzhou Thanks Electronic Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Thanks
Model Number AK-7216N
Type Digital Camera
Style Bullet Camera

Specifications

1.H.264 4CH DVR,

2.Recording  in 4ch D1
3.DI/HDMI/960H/3G smart phone/Email

4.Cloud service no need to set IP address.





Model

AK-7216N

System

GUI:

Graphic User Interface(OSD Menu)

Operation system:

Linux(embedded)

Multiplex Operation:

Pentaplex : Preview, record, playback, backup, network

Video/ Audio input

password security :

Multi-user management operation

Analog video input:

4CH,BNC, 1.0p-p, 75Ω,

Audio input:

1CH, RCA, 2.0Vp-p,600kΩ

Video/Audio output

HDMI Output:

support

VGA output:

1CH, resolution: 800*600, 1024*768,1280*1024

Display:

1ch / 8ch optional

Video standard:

PAL/NTSC

CVBS Output:

1CH,BNC, (1.0Vp-p,75Ω)

Resolution: PAL (704*576), NTSC(704*480)

Audio output:

8CH, RCA, (Linear electrical level, 600Ω)

Video/Audio encoding parameters

Video compression:

H.264

Display frame rate:

PAL: 100fps (4 x 25 fps)NTSC: 120fps (4 x 30 fps)

Record frame rate:

PAL: 100 fps(4 x 25 fps) NTSC:120 fps(4 x 30 fps)

video coding resolution:

4ch x D1(704X576)

video frame rate:

1-25FPS

video bit rate:

changeable and fixed bit rate(optional)

Stream type:

composite/ video

Audio compression:

ADPCM

Recording Mode:

Support normal / timer / alarm / motion detection recording

search video files :

By time period / channel / video type

Audio bit rate:

8-32kbps

Dual steaming:

support

Mobile phone monitoring:

Android / iphone / blackberry / windows / symbian

Recording resolution:

Recording: 4ch D1 Playback: 2ch D1

Synchronous Playback:

4ch

Hard Disk Driver

Type:

1 SATA interface

capacity:

Maximum 3TB HDD

recording type(Audio) :

audio and video recording simultaneously

remote control /mouse

support

Network:

Support IE/PPP0E/DDNS, DHCP,DDNS,PPPoE, IE view, and CMS central control

NAT

Support

Network interface:

1 RJ45 10M/100M, adaptive Ethernet interfaces

Serial interface:

1 standard RS-485 serial interface

interface:

2, USB 2.0

software upgrade:

Support USB/ network upgrade

Others

Power supply:

DC12V@2A

consumption(without HDD)

≤15W (Without HDD)

Working Temperature:

-10°C--+55°C

working Humidity:

10%--90%







cheap full D1 h.264 16CH NVR,P2P, cloud service, 4CH D1 play back only
Our advantage:

Good quality with two years warranty!

Soon deliver date 3-5 days.

2013 new design camera housing help you catch the market

Payment term:

Accept TT in advance, Paypal, West Union



Deliver date:



3-5 days after getting your bank slip



Shipment:



By TNT, DHL, FEDEX express,  By air or By sea.
