Specifications
1.L band satellite optical receiver2.Standard type
3.-13~+2dBm input power range
4.950~2600MHz
5.build in CWDM
L -band satellite optical receiver build-in CWDM
The RD-120D L-Band Satellite Product Series is a kind of SAT-IF Optical Receiver w ith high performance a nd h igh index. Working in 950-2600MHz b andwidt h, with low power consumption , suitable for FTTH, FTTP fiber
access network. It is really an excellent cost performance DBS n etwork ONU.
RF Typical Performance | |||||||
Parameter | Units | Min Typical Max Supplement | |||||
Frequency | MHz | 950 | 2600 | ||||
Output Level | dBµv | 68 | 88 | ||||
Flatness | dB | ±1.75 | 950~2600MHz | ||||
Port | 1 | ||||||
RF port | F-female | ||||||
Return loss | dB | -13 | |||||
Output Impedance | Ω | 75 | |||||
CNR | dB | 40 | |||||
IMD | dB | 40 | |||||
Optical Typical Performance | |||||||
Parameter | Units | Min Typical Max Supplement | |||||
Wavelength | nm | 1530 | 1550 | 1570 | |||
Responsivity | A/W | ≥0.9 |
| ||||
Return loss | dB | ≥55 | |||||
Input optical power | mW | -13 | +2 | ||||
Optical connector | LC/APC | SC/APC or LC/APC | |||||
General feature | |||||||
Parameter | Units | Min Typical Max Supplement | |||||
Power supply | V | 12 | |||||
Power consume | mA | 80 | 90 | 100 | |||
Work temp | °C | -20 | +55 | ||||
Storage temp | °C | -40 | +85 | ||||
Size | cm | 16*10.5*2.8 | W×D×H | ||||
High bandwidth 950~2600MHz | |
| Low light-receiving -13dBm | |
| Build-in CWDM | |
| Operating Wavelength 1550nm | |
| Wall-mounted metal housing | |
| F-female 75ohm RF Output | |
| Main application | |
| Satellite FTTH networks | |
| L-Band fiber distribution networks |
We are manufacturer of all CATV optical equipments such as FTTH optical receivers, Optical transmitters, Optical amplifier-EDFA , SAT-IF optical transmitters and receivers, Optic Transceiver Module and Optical Fiber Test instruments.
If you need optical equipments,please contact with me without hesitation!
Skype: china-miya
Mobile: 86-18936073153
Tel: 86-571-81023371
Fax: 86-571-81023367
http://cnruidian.en.china.cn
