1550nm Fiber Optic CATV signal Amplifier RED5000
- 100 Piece / Pieces per Month
- Shanghai/Shenzhen
- T/T L/C D/P D/A Credit Card PayPal
- ZTE 5928E, RS-5928E, RS-59EC-PWR-AC10, RS-59EC-PWR-DC10, 24 GE RJ45 + 1 expansion card ZTE ZXR10 5928E 5952E 5916E RS-5916E RS-
- ZTE 2952E, RS-2952E-AC, RS-2952E-DC, 48 FE RJ45 4 GE SFP ZTE ZXR10 2952E 2928E 2918E 2910E
- ZTE 3950-28TM, RS-3950-28TM-AC, 24 FE RJ45 + 2 GE SFP + 1 expansion card slot ZTE ZXR10 3950
- ZTE 2950-18TC, RS-2950-18TC-AC, 16 FE RJ45 + 2 GE Combo ZTE ZXR10 2950
- ZTE S2XF48A, 48-port 10GE SFP+ optical interface ZTE ZXR10 8902E 8905E 8908E 8912E RS-8902E RS-8905E RS-8908E RS-8912E
- ZTE 5250-28PM-H, RS-5250-28PM-H, 20 GE RJ45 (POE/POE+) + 4 GE Combo ports + 1 expansion card ZTE ZXR10 5250
Product Details
Place of Origin: | Sichuan, China | Brand Name: | Ruidian | Model Number: | RED5000 |
Product Description
Specifications
1.1550nm fiber optic CATV amplifier2.SNMP function optional
3.Famous pump laser
4.Multiport optional
5.Print logo free
1550nm Fiber Optic CATV Signal Amplifier RED5000
Product description
RED5000 series is a CATV booster optical amplifier with gain spectrum band within 1530~1560nm. It has low noise figure, high-saturated output power. It is applicable for central bureau, sub-bureau and line relay, as well as other optical communication network.
Features
Dual mechanic cooler in the housing and inside iron box to protect the laser. Work a long time. |
RJ45 port for SNMP remote management. |
RS232 for local management. |
Adopts JDSU, Fitel and Bookham Pump laser. |
Good stability, VFD or LED displays the working conditions, good trouble alarm system. |
Power supply 90V ~ 265V AC or -48V DC for the user’s choice. |
Max output can reach 27dBm. |
Parameters
Parameter | Units | Typical |
Input | dBm | -3 ~ 10 |
Wavelength | nm | 1530 ~ 1560 |
Output Stability | dB | ≤0.2 |
Polarization Sensitivity | dB | <0.2 |
Polarization Dispersion | PS | <0.5 |
Optical Return Loss | dB | ≥45 |
Fiber Connector | FC/APC or SC/APC | |
Noise Figure | dB | <4.5(0dBm Optical Input) |
Network Interface | RJ45(SNMP) / RS232 / RS486 | |
Power Consumption | W | 50 |
Power Supply | V | 220VAC(110 ~240) or -48VDC |
Working Temp | °C | -20 ~ +85 |
Size | 19″* 15″* 1.75″ | |
Weight | Kg | 5 |
Conversion of Optical Power
Items | Parameter | ||||||||
5014 | 5015 | 5016 | 5017 | 5018 | 5019 | 5020 | 5021 | 5022~27 | |
Output (dBm) | 14 | 15 | 16 | 17 | 18 | 19 | 20 | 21 | 22~27 |
Output (mW) | 25 | 32 | 40 | 50 | 63 | 80 | 100 | 125 | 160~500 |
Order information
Module | Output power | Output port | SNMP | Optical connector | Power supply (PS) | No. of PS |
RED5000 | 14~27dBm | 1,2,4,8,16 | With/Without | SC/APC, FC/APC | -48VDC/220VAC | 1,2 |
We are manufacturer of all CATV optical equipments such as FTTH optical receivers, Optical transmitters, Optical amplifier-EDFA , SAT-IF optical transmitters and receivers, Optic Transceiver Module and Optical Fiber Test instruments.
If you need optical equipments,please contact with me without hesitation!
