250kg/h Sugar Grinder

Sugar Grinder

This machine is grinding sugar to be sugar powder as required. The max. capacity is 250kg/hour.

There are screws to send sugar to the grinding device,after grinding, there will be a filter and the sugar powder will flow to the bag and the big grains will be ground again.

Fineness degree before grinding is 0.5-2mm and after grinding is 100 mesh.

The hopper and cover of the machine are ss304, frame and screws are iron, grinding device is Manganese steel.

Technical Data:

Model                                             FTJ250

Capacity                                       250kgs/hour

Spindle Motor Power                7.5kw

Feeder Motor Power                1.5kw

Spindle Speed                           3800r.p.m

Dimensions                               1240x 960x1733mm

Packing Size:                            1300x1500x2400mm

Weight:                                       N.W. :500 kg G.W.650 kg
