NTM-201B Automatic vacuum continue microfilm cooker and depositing line for flat lollipops(with automatic sticks putting device)
Technical data:
Model |
NTM-201B-2 |
Capacity(pcs/h) |
25000pcs/hour |
Speed |
25~45 n/min |
Shape of candies |
popsicle, windmill |
Weight of candy |
10g |
Steam consumption |
400kg/h~600kg/h, 0.5~0.7MPa |
Steam pressure | |
Compressed air consumption |
0.3m3/min |
Compressed air pressure |
0.4~0.6MPa |
Cooling requirement |
20-25℃(temperature),55%(humidity) |
Electric power needed |
30kW/380V |
Size of line |
17(L)X2.8(W)X2.7(H) |
Gross weight |
7000 kgs |
List of main parts:
ITEM |
EQUIMENT |
QTY |
1 |
200L -300L Dissolver(Inner layer SUS304 Stainless Steel)
|
1 |
2 |
High shear emulsifier equipped with ABB motor
|
1 |
3 |
260L Storage tank with mixer(SUS304 Stainless Steel)
|
1 |
4 |
Micro-film cooker(SUS304 Stainless Steel shell) 300kg/hour |
1 |
4-1 |
Frame and support(SUS304 Stainless Steel) |
1 |
4-2 |
Pre-heater(SUS304 Stainless Steel shell) |
1 |
4-3 |
Vacuum chamber(SUS304 Stainless Steel) |
1 |
4-4 |
Micro-film cooking room(SUS304 Stainless Steel) |
1 |
4-5 |
Water ring vacuum pump with steam water separator |
1 |
4-6 |
Feeding pump: piston dosing pump |
1 |
4-7 |
Discharging pump: roots pump (stainless steel) |
1 |
4-8 |
Steam reducing valve, steam trap (Spirax Sarco) |
2 |
4-9 |
Accessory and piping |
1 |
4-10 |
Main motor:7.5kw |
1 |
4-11 |
PLC programmer, Touch screen(Weinview), electric components(Schneider), Emerson inverter |
1 |
5 |
Depositing unit (304 stainless steel shell), 11m |
1 |
5-1 |
Main driver |
1 |
5-2 |
Lollipop stick putting device |
1 |
5-3 |
Color and flavor mixer |
2 |
5-4 |
(NIKKISO)/Dosing pump |
4 |
5-5 |
PLC programmer, Touch screen(Weinview), electric components(Schneider), pneumatic components(AirTAC) ,Emerson inverter |
1 |
5-6 |
Double color hopper, distributing unit, piping and accessory |
1 |
5-7 |
Candy mould(flat) |
580PCS |
(Cooker)
