HBS-SF600A Tabber and Stringer Machine for photovoltaic modules

FOB Price

USD $70,000 - $80,000 / Unit

1 Unit(Min.Order)

Supply Ability 200 Unit / Units per Month
Port ShenZhen or GuangZhou
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Brand Name	HAOBANGSHOU
Model Number	HBS	Voltage	380V
Current	10A	Rated Capacity	4.5KVA
Rated Duty Cycle	80%	Dimensions	390015001800mm
Weight	2500kg	Usage	Welding Machine
Certification	CE ISO	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

HBS-CH600A Tabber and Stringer Machine for photovoltaic modules

Main technical parameters

NO.	Items	Parameters	Remarks
1	Name	solar battery cells automatic tabber stringer
2	Model	HBS-SF600A
3	Welding Speed	About 450~600Pics/Hour
4	Battery cells dimension	30~125125mm;30~156156mm
5	Maximum length of battery string	1950mm
6	Interval between battery cells	0.8-2.5mm(adjustable)
7	Debris rate	≤3‰
8	Qualified rate	≥98%
9	Welding stings quantity	single string
10	Welding way	Infrared heating welding
11	Welding Temperature	Normal temperature~400℃ (Adjustable)
12	Lamp working life	≥3000 Hours
13	Operation Interface	PLC Touch-screen
14	Language	Chinese or English(switchable)
15	Power requirements	50-60Hz/AC380V
16	Peak power	12Kw

17	Rated power	10kw
18	Air requirements	0.4-0.8Mpa clean and dry air
19	Gas consumption	About 200Litres/Hour
20	Machine dimension	L3900W1500H1800(mm)
21	Machine weight	About 2.5 tons

Package and shipping

Welcome to our factory and expect our cooperation

HBS Automatic Device & Technology Co.,Ltd is a new high-tech enterprise which devotes to researching and developing automatic devices and PV modules assembly-line products in the solar industry. It covers research and development,design,manufacture,sales and service,and has high-quality R & D team.

Our company,based on the idea of helping the solar module production enterprises to save labor costs,increase productivity and improve stability,focus on R&D innovation,safety and efficient production,precision strict test to ensure availability and stability of the machine.

Now our main products include:solar battery cells automatic tabber stringer,solar backing cells(EVA/TPT)automatic cutting machine,solar backing manually cutting machine and so on.

As a new energy,automation of the solar industry is bound to become an inevitable development trend! We would like to create a better future with you.
