Home > Products > Ungroup > 110, 220VAC Normal Closed Water oil Solenoid Valve,Oil Air Solenoid Valve
110, 220VAC Normal Closed Water oil Solenoid Valve,Oil Air Solenoid Valve
- 5000 Piece / Pieces per Month
- Chongqing China
- T/T Credit Card
Product Details
Standard or Nonstandard: | Standard | Structure: | Angle | Pressure: | Medium Pressure |
Power: | Solenoid | Material: | Brass | Temperature of Media: | Low Temperature |
Media: | Other, Gas, water, gas, oil, air | Port Size: | 1/4 inch | Place of Origin: | Chongqing, China |
Model Number: | 2W025-08 | Brand Name: | Haodong | Application: | General |
Product Description
Product Name: 110/220VAC Normal Closed Water Solenoid Valve,Oil Air Solenoid Valve (2W-025-08)
2W series solenoid valve are 2/2way, direct action type, are most popular valves for many conditions, especially in the water treatment system, such as water heater. It can start working at zero differential pressure. This type of valve can change the coils to be as explosion-proof solenoid valve or water-proof solenoid valve to be used in water.
Specification
1.Item No.: 2W025-08 ;
2.Normal close type
3.Wide application, suitable for various kinds of gas and liquid
4.Operating temperature range: -5 ~ 80 degree °C
5.Joint pipe bore: 1/4 inch
6.Aperture of flow ratea: 2.5mm
7.High quality
petitive price.
Technical
Specs and Descriptions | 2W040-10 | 2W160-15 | 2W200-20 | 2W250-25 | 2W350-35 | 2W400-40 | 2W500-50 |
Aperture of flow rate | 4 16 | 20 | 25 | 35 | 40 | 50 | |
CV Value | 0.6 4.8 | 7.6 | 12 | 24 | 29 | 48 | |
Port Size | 3/8” | 1/2” | 3/4” | 1” | 1-1/4” | 1-1/2” | 2” |
Operation Fluid viscosity | Below 20CST | ||||||
Working Pressure | Water/Oil:0~0.5Mpa Air/Gas:0~0.7Mpa | ||||||
Media | Water, Oil, Gas, Air | ||||||
Motion Pattern | Direct Drive | ||||||
Type | Normal Closed , Normal Open | ||||||
Max Pressure Resistance | 10.5MPA | ||||||
Working Temperature | -5~+80 °C | ||||||
Voltage Range | ±10% | ||||||
Material of Body | 2W:Brass; 2S: Stainless Steel | ||||||
Material of Oil Seal | NBR/ VITON |
