company profiles :
Established in 2005 ,Chongqing Haodong Technology co.,Ltd is a mannufacturer specialiaed in the research, development and production of infrared catalytic burner.
The inrared burner is based on catalytic combustion patent technique which is advanced in the field and which is developed by Sichuan Chemical Works Ltd. Now they have been successfully applied in coating,foods drying and baking ,drying process, heating at low and middle temperatures, warming , heat preservaton,Now we mainly sell infrared gas burner,room heater ,chain,and other products
Supplier assessment certificate
Summary of industrial drying machine :
This infrared burner uses rare-earth as catalyst, which is with relatively low cost, higher activity than noble metal. The burning occurs on the covering catalyst and radiate infrared ray, energy transfer can reach 95%.And can save10%-20% energy than other non-catalytic infrared ceramic plate.
Advantage of industrial drying machine :
1. No flame catalytic combustion.
2. heat mainly infrared radiation.
3. guarantee the gas burning fire and burn holes never carbon.
4. Low emission of poisonous and harmful material
industrial paint drying machine heater parts HD262
Model |
Length (mm) |
Width (mm) |
Height (mm) |
Weight (kg) |
Consumption |
Heat Output |
Inlet Port (Inch) |
|||
NG |
LPG |
|||||||||
m3/h |
kg/h |
KW/h |
Kcal/h |
BTU/h |
||||||
HD262 |
930 |
130 |
175 |
15 |
0.8 |
0.74 |
10.9 |
9360 |
41972 |
3/8 |
Material of industrial drying machine :
Shell:gray cast iron
Upper cover:stamped stainless iron
Burning net:Fe-Cr-Al material
Nozzle:brass
Core components:cordierite honeycomb burner plates with rare-earth catalyst-coated
Technical parameters:
|
Items
|
Technical parameters |
|
Types |
natural gas (NG),liquefied petroleum gas (LPG)
|
Light-off temperature |
≥350 |
complete combustion temperature |
≤380 |
|
Heat source temperature
|
around 850 |
Baking temperature range |
30---850 |
Wavelength range |
1.9m--15m |
|
Furnance pressure natural |
Gas 150mmAq;liquefied petroleum gas 280mmAq
|
Advantages of industrial drying machine :
1. Energy saving: conversion rate:≥90%
2. Environmental protection: CO≤80ppm;NOx≤10ppm;CHx≤50ppm
3. Whole combustion: 95% of energy released in the form of infrared ray ;heating the objects directly
4. Long life:≥11000hr
5. Easily installed
6. Flameless & smokeless
Application of industrial drying machine
1. Coating Industry: forging heat coating, liquid, powder coating, pre-heating the water to deal with dry acid.
2. The food industry: drying for processed food such as cookies, egg rolls, snow rice cakes, shredded squid, fish sauce, ham etc;tea processing and baking.
3. Agriculture and animal husbandry: keeping warm for a variety of birds, the livestock shed;grain drying.
4. Food and beverage industry: all kinds of barbecue, fruit and vegetable dehydration.
5. Drying operation in printing and dyeing, paper, wood, carpet and other industries
6. Bake ceramic mold industry, the Health and embryos, the surface drying of glazed ceramic tiles.
Factory & Packing Photos:
Commpany honours
Contact information Trade manager:cn1500440252
Whatsup:+8613883514635
If any need, welcome to contact us freely!!
We'll do our best to serve for you!!
