Heat press machine / hot press / plywood hot press / hydraulic hot press BY214*8/120(3)D
- 20 Set / Sets per Month
- Qingdao
- T/T
You May Like
-
Press machine / hot press / plywood hot press BY214*8/120(3)D
-
plywood cold press, pre press
-
Particle board hot press BY21-4*8/1200(3-15)D
-
hydraulic hot press/hot press/cold press/hot and cold press BY21-4*8/900(3-15)D
-
plywood multi opening hot press BY21-4*8/1200(3-15)D
-
plywood making machine / pre press machine/veneer cold press BY814*8/400 ton
Product Details
| Condition | New | Type | Hot Press Machine | |
| Place of Origin | China | Brand Name | SEFE | |
| Model Number | BY214*8/120(3)D | Voltage | 380V | |
| Power(W) | 5.5K | Dimension(L*W*H) | 4900*1600*2150MM | |
| Weight | 7,000kgs-10,000kgs | Certification | CE ISO9001 | |
| Warranty | 1 years | After-sales Service Provided | Engineers available to service machinery overseas |
in bulk or wood box.
Product Description
heat press machine / hot press / plywood hot press / hydraulic hot press BY214*8/120(3)D
1. full-automatic and manual integration.
2.CE, ISO9001
3.Woodworking Machinery,plywood hot press,veneer hot press.
4.Model:BY214*8/120(3)D
5.Save Electricity 20% at least.
| Model | BY214*8/120(3)D |
| Quantity of layers | 3 layers (4 hot plater) |
| Pressure | 120T |
| Overall Dimensions | 4900*1300*2150mm |
| Motor power | 5.5Kw |
| Heating Platen( working table size) | 2700*1370*42mm |
| Heat Power | 30kw |
| Heating Platen | Seamless Steel Pipes( Heating with Oils) |
| Number of cylinders | 8 |
| Diameter of piston | 100mm |
| Valid travel of piston | 300mm |
| working pressure of high pump | 25Mpa |
| Gross Weight | 8500kgs |
1. Packing in Bulk or wood box.
2. Shipping: 20-30 days after deposit.
BASED ON MORE THAN TEN YEARS EXPORT EXPERIENCES IN WOODWORKING MACHINERY,WE OFFER A FULL LINE OF HIGH QUANLITY CHINA HOT PRESS,PRE-PRESS,SANDER,WOOD VENEER DRYER MACHINE.
Company Profile
Qingdao Sefe Trading Co., Ltd. is a subsidiary of Sefe Woodworking Machine Manufacturing Company. We are specialized in manufacturing woodworking machines, located in Qingdao, China. With over 50 years of experience in woodworking machine and metalworking fields, we have developed various series of woodworking machines, such as wide belt sanders, edge banding machines, slitter machines and vacuum press machines. In order to supply high quality products and excellent services, we are continually improving our products with the latest technologies according to the market prevailing requirements. In the past few years, we have already got CE and ISO9001 certifications. Our product quality is also well accepted by our overseas clients. We sincerely welcome every client to visit our factory and hope to cooperate with you in the future.
