Particle board hot press BY21-4*8/1200(3-15)D
1. full-automatic and manual integration.
2.CE, ISO9001
3.Woodworking Machinery,plywood hot press,veneer hot press.
4.Model: BY214*8/1200(3-15)D
5.Save Electricity 20% at least.
Model |
BY21-4'*8'/1200-11 |
Frame style |
Combination frame |
Quantity and Diameter of Cylinder |
6 units Φ320mm |
Nominal Pressure |
1200Tons |
Quantity of layers |
11 layers |
Separation between layers |
70mm |
Stroke of Cylinder |
1050mm |
No-load closing time |
About 15s |
Hydraulic system control method |
Manually/Automatic controlled |
Hydraulic system pressure |
25MPa |
Main motor |
11KW |
Pressurized motor |
7.5KW |
Main pump |
Shanghai Aviation 250 pump |
Pressurized pump |
10ml/rev plunger pump |
Heating platen(working table size) |
2700*1370*42mm |
Heating Meduim in the heating platen |
steam or heat transfer oils |
main frame steel plate thickness |
35,22,12mm |
Upper, Bottom crossbeam |
900,800,400mm |
Movable crossbeam |
2700*1370*400mm |
Dimensions of Main frame |
3560*1370*4240mm |
Weight |
32000KG |
Production Capacity |
about 30 sheets of plywood in one hour |
1. Packing in Bulk or wood box.
2. Shipping: 20-30 days after deposit.
BASED ON MORE THAN TEN YEARS EXPORT EXPERIENCES IN WOODWORKING MACHINERY,WE OFFER A FULL LINE OF HIGH QUANLITY CHINA HOT PRESS,PRE-PRESS,SANDER,WOOD VENEER DRYER MACHINE.
