china alibaba hydraulic valve for machine making
Features:
- Prefill valves brings a feature like check vales, which is able to used for special processing so then the flow is bigger than general usage.
- Prefill valves are a traditional threading type which can be coupled to comprehensive hydraulic system designs.
- The piloted pressure is adopted two steps and matched by area ratio which can be reduced piloted pressure and eliminated noise which made due to impulse.
Specifications:
Model Numbers |
Max. Pressure kgf/cm2 |
Rated Flow l/min |
Operated flow l/min |
Cracking pressure Kgf/cm2 |
Weight Kg |
||
NO PL |
USE PL |
NO PL |
USE PL |
||||
SG-16 |
210 |
300 |
450 |
300±70M |
450±70M |
0.12 |
30 |
SG-24 |
600 |
900 |
600±150M |
900±150M |
0.14 |
55 |
|
SG-23 |
1100 |
1600 |
1100±300M |
1600±300M |
0.16 |
105 |
|
Model Number:
SG |
24 |
L |
Series Number |
Port Size: |
Rotation |
Refill Valves |
16:2” 24:3” 32:4” |
None : 180 L:90 |
Company History:
Product process:
Q.How to request a manufacturing quote from LCH?
A.Give us a call or send us an E-mail (lch at .tw) with your purchase request.
Q.What are your quality control procedures?
A.LCH is equpped with high-tech, advaned cmputerized and self-inspection machineries, manufactures thousands of different parts in house to ensure the built-in quality and dependable performance. This is the reason hy LCH is recognized as on the world class quality level.
Q.How are orders packed and shipped?
A. Depends on customers' orders. All goods are packed with a plastic bag with an outer carton and a wooden pallet( fumigatation).
Q. Could LCH offer OEM service?
A.Yes. LCH is able to offer OEM with customers' brand name and trademark onto the product.
Q.Do LCH products come with a warranty?
A.Yes.LCH offer 1-year product life guarantee without abusive usage on all purchases which begins with the bill of lading.
