800mm belt width TUV qualified 18 Mpa coal mine CC cotton canvas conveyor belt
Cotton canvas conveyor belt called CC conveyor belt for short, medium and long distance transportation.
1.Deatail show for cotton canvas conveyor belt
1) specification for cotton canvas conveyor belt
| Fabric | Fabric structure | Fabric type | Fabric thickness (mm/p) | Strength (N/mm) | Cover thickness (mm) | Wdth (mm) | |||||||
| Warp | Weft | 2 ply | 3 ply | 4 ply | 5 ply | 6 ply | Top cover | Bottom cover | Cut edged | Round edged | |||
| Cotton CC | Cotton C | Cotton C | CC-56 | 1.10 | 112 | 168 | 224 | 280 | 336 | 2-8 | 0-4.5 | 400-2200 | 76-1600 |
| Polyester cotton TC | Polyester cotton TC | Cotton C | TC-70 | 1.00 | 140 | 210 | 280 | 350 | 420 | 1.5-8 | 0-4.5 | 400-2200 | 76-1600 |
2) feature
1. High initial modulus
2. High strength
3. Low elongation
4. Impact resistance
5. Suitable for medium and long-distance
3) standard
DIN22131, EN ISO 15236, SANS1366 and AS1333
2. General product process for cotton canvas conveyor belt
a. fabric type: CC-56 TC-70;
b. ply: 2, 3, 4, 5, 6;
c. tensile strength: 15Mpa, 18Mpa, 24Mpa;
d. cut edged or round edged.
3. Quality control for cc conveyor belt
1) test equipment
2) ISO9001:2008
3) TUV qualified factory for cotton canvas conveyor belt
4. Well packed coal mine conveyor belt and kinds of conveyor belt you can choose
Packed in pvc waterproof cloth or as require.
Shipment within 7-15 working days according to the quantity.
the conveyor belt we can supply:
steel cord conveyor belt, heat resistant conveyor belt, sidewall endless conveyor belt, corrugated sidewall conveyor belt, chevron v conveyor belt, fire resistant conveyor belt, ep conveyor belt, nylon conveyor belt, etc.
5. About us - Baoding Huayun Conveyor Machinery Co., Ltd.
Five reasons to choose us:
1. the manufacturer of conveyor belts, conveyor rollers, conveyor pulleys, conveyor brackets, etc.;
2. most advanced production equipment;
3. exquisite craft with CEMA DIN JIS standard;
4. passed the TUV, ISO9001:2008 and Safety of Approval for Mining Products;
5. high quality material purchasing channel and excellent after-sale service.
Know more information about the cotton canvas conveyor belt, pls contact us via the following ways:
