Flame Retardant Conveyor Belts Used in Underground Mines

Name: Flame Retardant Conveyor Belts Used in Underground Mines
Brand: Huayun
SKU: 101016561
Availability: InStock

US$ 5 - 54 MOQ: 50 Meters

Key Specifications

Place of Origin:

Hebei, China

Brand Name:

Huayun

Model Number:

flame retardant conveyor belts

Baoding Huayun Conveyor Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Xingang Port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Hebei, China

Brand Name Huayun

Model Number flame retardant conveyor belts

flame retardant conveyor belts

performance of flame retardant conveyor belts

Flame retardant conveyer belt is made from the whole belt core via dipping and plastifying in

polyvinyl chloride (PVC) dipping agent or sulfuration. It features largely in the high strength,

large freight volume and stable conveyance performance. Besides, it is fire retardant,

anti-static, shock resistant, wearable and corrosion resistant.

Usage for flame retardant conveyor belts
It is mainly applicable for the underground well haulage of coal mines, and also the conveyance

of materials for metallurgical and chemical industries. The whole core fire-retardant conveyer

belt is divided into 2 types.

two types: PVC, PVG

PVC type conveyer belt's upper and lower layers are PVC coating cover,

single-sided tape thickness: ≥1.0mm;

PVG type belt's upper and lower layers are nitrile rubber and PVC,

single-sided tape thickness: 1.5mm-4.5mm.

PVC type conveyer belt's inclined angle: <16°;

PVG conveyer belt's inclined angle: <20°

Type and technical parameter of PVC conveyor belt

Standard MT914-2008						Safety factor 10 (Breaking strength*1/10)
The Slope <16°C						Safety factor 10 (Breaking strength*1/10)
Standard type	Degree	Breaking strength ≥,N/mm		Tensile yield≥,%		Advising Mindiameter of Transmission Drum
Standard type	Degree	Longitudinal	Transverse	Longitudinal	Transverse
680S	4th	680	265	15	18	320
800S	5th	800	280			400
1000S	6th	1000	300			500
1250S	7th	1250	350			500
1400S	8th	1400	350			630
1600S	8th	1600	400			750

Type and technical parameter of PVG conveyor belt

Standard MT914-2008 BS3289 HG2805						Safety factor 10 (Breaking strength*1/10)
Standard type	Degree	The slope <20°C
		Breaking strength≥,N/mm		Tensile yield≥,%		Recommend minimum roller diameter
		Longitudinal	Transverse	Longitudinal	Transverse	Recommend minimum roller diameter
680S	4th	680	265	15	18	400
800S	5th	800	280			500
1000S	6th	1000	300			630
1250S	7th	1250	350			750
1400S	8th	1400	350			750
1600s	9th	1600	400			750
