Help Center500mm Belt Width 18MPa CC-56 Conveyor Belt for Short and Medium Distance Loading
Related Products
-
ISO Standard Heat Resistant Cotton Canvas Conveyor Belt for Cement PlantUS$ 30 - 50MOQ: 50 Meters -
800mm Width Corrugated Sidewall Conveyor BeltUS$ 8 - 50MOQ: 100 Meters
-
Conveyor Belt Manufacturer 650mm Width Rubber Conveyor BeltUS$ 8 - 50MOQ: 100 Meters
-
PVG Rubber Conveyor Belt Mining Machinery AccessoriesUS$ 30 - 50MOQ: 50 Meters
-
800mm Belt Width 15 Mpa 4 Ply NN Nylon Fabric Conveyor BeltUS$ 10 - 30MOQ: 50 Meters
NN100, NN150, NN200, NN250, NN300, NN400 , NN500, NN600
Standards for CC-56 conveyor belt
Besides General Nylon Belt, there are Fire-resistant type, Cold-resistant type, Wear-resistant type,
Features of CC-56 conveyor belt
1.Natural rubber Thin belt body with high strength, light weight;
2.Anti-abrasive, impact resistant, corrosion resistant;
3.Softy belt body, good flexibility, excellent trough;
4.Vulcanization molding;
5.Long service life.
Specification and technical data of multi-ply CC-56 conveyor belt
Fabric |
Fabric structure
|
Fabric Type |
Fabric Thickness (mm/p) |
(N/mm) strength |
Cover thickness (mm) |
Width (mm) |
Length (m) |
||||||
|
Wrap |
Weft |
2ply |
3ply |
4ply |
5ply |
6ply |
Top cover |
Bottom cover |
|||||
|
Cotton CC
|
Cotton C |
Cotton C |
CC-56 |
1.40 |
112 |
168 |
224 |
280 |
336 |
3-12 |
1.5-4.5 |
400-2200 |
≤300 |
|
Polyester Cotton TC |
Polyester Cotton TC |
Cotton C |
TC-70 |
1.20 |
140 |
210 |
280 |
350 |
420 |
3-12 |
1.5-4.5 |
400-2200 |
≤300 |
Adhesion and elongation of CC-56 conveyor belt
Belt carcass |
Adhesion strength |
Elongation |
|||
|
Between plies N/mm |
Between rubber and carcass N/mm |
Longitudinal elongation elongation at break%≥
|
Longitudinal elongation at reference load%≤
|
||
|
Cover thickness ≤1.5mm |
Cover thickness ≥1.5mm |
||||
Cotton canvas |
≥3.2 |
≥2.1 |
≥2.7 |
10 |
4.0 |
According to the customer’s requirements, the belts could be made into endless belt, and the covering
rubber could be made into pit, chevron and level type etc.
Production process for cc-56 conveyor belt
Useage
It is suitable for conveying materials at medium or long distance
and under conditions of heavy load and high speed.
Our research and development center, test equipment
Certifacation
Our company and customers
For more details,please inquiry us!
