Low Coefficient of Friction Impact Conveyor idler With Maintenance-free
- 720000 Piece / Pieces per Month
- Tianjin port
- T/T Credit Card
- Hand tool parts castings
- OEM/ODM steel air tool parts / needle bar bushing
- air chuck,air accessory,pneumatic tool parts
- Air conditioner parts develop stamping tooling die
- Investment Casting Pneumatic tools accessories with Stainless Steel and Alloy Steel Materials
- customized high quality Milling Tools
Product Details
Place of Origin: | Hebei, China | Brand Name: | Huayun |
Product Description
Inner structure of conveyor roller with bearing housing
specification of conveyor Roller with bearing housing
Standard | DINCEMAJISETCISOMA | |
Color | redblueblackas require | |
Pipe | 1) maerial:roller pipe/carbon steelQ235 | |
2)diameter: 51,60,63.5,76,89,108,127,159mm | ||
3)thickness:1.8,2.0,2.2,2.5,2.75,3.0,3.25,3.5,3.75,4.0mm | ||
4)brand:BAOLAI.GH | ||
Product description | steel industrial used sreel pipe Convery Rollor(ISOMA factory) | |
Shaft | 1) material:A345#steel | |
2) diameter:20,25,30,35,40mm | ||
Bearing | 1) type:Deep groove ball bearing with C3C4 | |
2) size:6104.6204.6205.6206.6306.6308 | ||
3) band:C&UHRBLYCZWZNWHSKFNSK | ||
Bearing housing | 1) type:pressed housing,cast iron bearing housing,polymer housing | |
2) brand:Trintiy,special customized for Huayun | ||
Seals | 1) type:general use(oylon),Double labyrinth seal.TR seal | |
2) grease:Lithunm grease lubricant | ||
3) feature:multiple labyrinth seal.water proof,dust proof | ||
Seals | automatic double end weld bearing housing | |
Painting | electric static spraying painting | |
Mini order | 50 pieces | |
Packing | standard plastic package,wooden package box,iron shelf or as require | |
Port of loading | Tianjin,China or any other Chinese seaport | |
Date of shipment | 50-30 days according to the quantity/as require | |
Transport mode | by air,sea,express mail, etc | |
Payment Term: | Paypal,Western Union,Money Gram,T/T,L/C at sight,etc |
manufacturing steel pipe Conveyor Roller with bearing housing
Available color: red, blue, black, as require
Axial load: >10KN
Axial displacement: ≤1.2mm
Radial runout: ≤0.5mm
Rotation resistance: ≤3.5N
Water seal: ≤150g
Our steel pipe Conveyor Roller with bearing housing passed the ISO9001:2008
feature of conveyor roller with bearing housing
1) Corrosion resistance
2) High hardness, strong wear resistance
3) Good sealing
4) Long life - more than 30,000 hours
5) Low operation costs
Ceramic surface: formation of oxide films, the surface is smooth, non-stick materials, contact with the conveyor belt with small coefficient of friction, reducing the winch driver
kinds of Convey Roller with bearing housing
