Hot price ! ac brushless synchronous alternator made in China

Specifications

ac brushless synchronous alternator made in China
1, 100% copper
2, factory directly
3, ISO CE SGS CQC
4, reliabel

Hot price ! ac brushless  synchronous alternator made in China

Features:

1) Any permanent magnetic generators, providing invariable excitation on all occasions.



2) Easy to be connected with power network or other generators. Standard 2/3 pitches windings check excessive midline current.



3) Balanced rotor with single or two sealed ball bearings



4) Convenient installation and maintenance with easy access to terminals, rotating diodes and coupling bolts





ac brushless  synchronous Alternator Technical Datas

TYPE	Rated Power(1500rpm 50HZ 400V)							KG
	Continuous/40			Stand by/40		Stand by/27
	H125K			H150K		H163K
	KVA	KW	(%)	KVA	KW	KVA	KW
DHG164B	9.4	8	78.8	11	8.8	12	9.6	90
DHG164C	12.5	10	80.6	13.8	11	15	12	96
DHG164D	15	12	81.2	17.5	14	20	16	100
DHG184E	20	16	84.5	22.5	18	25	20	120
DHG184F	25	20	86	27.5	22	30	24	150
DHG184G	30	24	86.3	32.5	26	35	28	160
DHG184H	37.5	30	86.6	40	32	41.3	33	216

DHG224B	42.5	34	87	45	36	47.5	38	250
DHG224C	50	40	88	52.5	42	55	44	270
DHG224D	60	48	88.6	62.5	50	65	52	290
DHG224E	72.5	58	90	77.5	62	80	64	320



Three phase brushless alternators  We Make Is from 6KW to 1000KW.

WHAT WE DO AT DELLENT

• Having self-own plants producing for stators ,rotors and some related die-casting parts since from 1995

• Stamping of lamination

• Rotor die-casting

• Winding and inserting – both manual and semi-automatically

• Vacuum varnishing

• Machining shaft, housing, end shields, etc…

• Rotor balancing

• Painting – both wet paint and powder coating

• Assembling

• Packing

• Inspecting spare parts every processing

• 100% test after each process and final test before packing.

WHAT DELLENT CAN DO FOR CUSTOMERS

• Dellent supplies standard products to customers.

• Dellent supplies standard products under customers’ brands and packaging, etc

• Dellent develops any new products together with the customers.
