round bottle single side Labeling Machine
1. The Scope of Application
This is our upgraded product, adapt to multi-function automatic labeling machine of round bottles, square and flat bottles in food, medical and daily chemical industry. Adapt to separate bottles.
2. Device Characteristic
.Machine-wide adoption of a mature technology PLC control system, so that the whole stable, high-speed
.Operating system using touch-screen control, simple, practical, efficient
.The advanced technology of printer code machine, so that the writing clear, fast and stable
.The upgraded three-dimensional butterfly designed station, the angle of the labeling can be adjusted, adapt to the separate bottles
.Screw suppression, high accuracy
.Synchronization chain agencies, to ensure calibrate stably and accurately
.Labeling transparent label without bubble, self-adhesive label without wrinkle
.The large scope of application, a multi-function machine and high adaptable
3. Device Advantages
.The advanced function, simple operation, and compact structure
.Using slat conveyor, high stability of bottles
.The imported electric elements, stable performance, low failure rate
.Adopt servo labeling system, high speed and accuracy
.With no material non-labeling, fault alarm functions
.Single operation can also be used on-line;
4. Technical Parameters
Driving Mode |
Servo system |
Operating direction |
Left or Right |
The Amount of Labeling(bottle/min) |
50-100 |
Labeling Speed(m/min) |
≤35 |
Labeling Accuracy |
±1.0 mm(subject to the roughness of the plane) |
The application specification of label |
Graze, transparent or not |
Label code(mm) |
76 mm |
Label diameter(mm) |
300 mm(max) |
The size of label |
Width 15-150 mm length 15-300 mm |
Weight(kg) |
500 |
Power(w) |
800W |
Voltage |
AC220V 50/60HZ Single side |
The application of bottle(mm) |
2400(L) 1300(W) 1500(H)mm |
