Specifications
slitting and rewinding machine (horizontal type computer control) for slitting and rewinding such various roll materials as BOPPMACHINE NAME:HFQ Series High Speed Slitting And Rewinding Machine
Introduction:
1.This machine is mainly used to cut paper,laminated film, aluminum foil, etc. 2. Entire machine is controlled by PLC(two vector motors), man-machine interface,screen touch operation
3.Unwinding part adopts the import magnetic powder brake, realizes by the PLC automatic counting,as well as constant tension control for unwinding
4.transmissiont part uses the vector frequency conversion motor,realize the constant line speed control.
5.Unwinding part is shaftless, adopt air cylinder equipment, vice- clamps electrically operated by the lead screw to adjust.
6.Rewinding part uses the vector
frequency conversion motor,to drive magnetic powder clutch,realized by the PLC automatic diameter counting, auto tensity control.
7.Auto meter presetting,auto meter counting,auto stoppage,etc.
8.EPC error correction device is positive to assure the accuracy
Main Technical Parameters:
Width of machine |
1300mm |
Max.diameter of raw material |
φ1000mm |
Max rewinding diameter |
φ600mm |
Speed of machine |
0-300m/min |
Total power |
9kw |
Overalldimensions(LxWxH) |
1800×2800×1600mm |
Weight of machine |
2800kg |
MACHINE LIST
Name |
Spec. |
Quantity |
Origin |
Main Control PLC |
Fx2n |
1 PC |
Hollysys |
PLC HMI |
Color Screen 5.7” |
1 PC |
TAIWAN EV |
Inverter |
5.5/3.7KW Vector Expression |
Each 1PC |
INOVANCE |
Magnetic Powder |
100NM |
1PC |
TAIWAN |
Motro |
5/4KW |
Each 1PC |
XinNianHua Motor JiaXing |
motor encoder |
|
2 PCS |
OMRON |
Unwinding Automatic Tension Controller |
US-60MTA |
1 PC |
Shanghai Tension Automatic Equipment Co.,Ltd. |
Tension Sensors |
TD50-2000N |
2 PCs |
Shanghai Tension Automatic Equipment Co.,Ltd. |
Pneumatic Component |
|
1PC |
AIRTAC |
Electric |
|
|
CHINT |
