Pvc Shrink Film Label Printing Machine

Pvc Shrink Film Label Printing Machine thumbnail-1
Pvc Shrink Film Label Printing Machine photo-1
US$ 1 - 2 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Food, Beverage, Commodity, Medical, Chemical, Other, Apparel, Food, Beverage, Commodity, Medical, Chemical, Machinery & Hardware, Apparel
Packaging Type:
Bottles
Contact Supplier Request Quote Chat Now
Wenzhou Xiaohai I/E Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Food, Beverage, Commodity, Medical, Chemical, Other, Apparel, Food, Beverage, Commodity, Medical, Chemical, Machinery & Hardware, Apparel
Packaging Type Bottles
Packaging Material Plastic
Automatic Grade Automatic
Driven Type Electric
Voltage 380v
Power 55kw
Place of Origin Zhejiang, China
Brand Name XIAO HAI
Model Number GWASY
Dimension(L*W*H) 16300x3400x3100
Weight 10TONS
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.rotogravure type printing machine to print highest quality for roll materials.
2.print BOPP,PVC label,paper,PET,



shrink film label printing machine



pvc shrink film label printing machinepvc shrink film label printing machinepvc shrink film label printing machine



Machine name:high speed computer control gravure printing machine

Usage:
This machine is suitable for multi-color once-through continuous
printing for such roll film materials with excellent printing
performance as BOPP, PET, PVC, PE, aluminum foil and paper, etc.

Performance and Features
1.Every control module of the automatic color register system is
 equipped with microprocessor and can correct the deviation of
color register quickly and accurately.
2.Main motor equipped with frequency converter for speed regulation
3.Unwinding tension adopts automatic tension controller and
magnetic powder brake.
4.Rewinding adopts torque motor, double-station automatic turret.
5.Closed oven and independent heating hot air blowing system,
automatic constant temperature system.
6.Pneumatic impressing system and pneumatic doctor blade system
7.Diaphragm-type pneumatic ink auto circulating system
8.Inflatable loading and unloading shaft
9.Printing linear speed and meter counting display
10.Shaft less printing cylinder loading device
 (Option:Shaft printing loading device)
11.Option: web video


Specification:




Model No. BSY-B8800 BSY-B81000

Effective Printing Width 800mm 1000mm


Max.Printing Speed 120m/min 120m/min

Max.Mechanical Speed 140m/min 140m/min

Max.Diameter of Unwind/Rewind 600mm 600mm

Inside Diameter of Roll Core 76mm 76mm

Diameter of Printing Cylinder 120300mm 120300mm

Accuracy of Computer Registration ±0.2mm ±0.2mm

Tension Control Range 025kg/Full Width 025kg/Full Width

Heating Power of Oven 124kw 144Kw

Total Power 140kw 161Kw

Weight of Machine 20000kg 25000kg

Machine Dimension(mm) 16300x3400x3100 16300x4000x3100






Remark:
This model is with eight colors.Also you can decrease or increase the color quantity from 1 color to 10 colors.If you have interest,please feel free to contact us,we will provide you details.thanks.



We have full production line machines,include:

1. rotogravure printinig machine to print the design



2. slitting machine    https://img13.fr-trading.com/product/217974163-0/slitting_and_rewinding_machine_cutting_machine_rewinding_machine.html



3. sleeve seaming machine   low speed type 80m/min  :  https://img13.fr-trading.com/product/1068380504-220000317/Central_Sealing_Machine.html

                                                    high speed type 200-300m/min     https://img13.fr-trading.com/product/461434271-219997346/HZF_Series_High_speed_bottle_sleeve_seaming_machine.html



4. sleeve piece cutting machine  :   https://img13.fr-trading.com/product/1330144509-219994404/cutting_machine_for_sleeves.html



5. sleeve inspection machine       https://img13.fr-trading.com/product/594650753-0/2013_Best_PVC_sleeve_label_inspecting_machine.html
