Elgiloy alloy
This Cobalt-Chromium-Nickel alloy gives a combination of high strength, ductility and good mechanical properties and is age hardenable. elgiloy also has excellent fatigue life, corrosion resistance in numerous environments and is non-magnetic.
Elgiloy Chemistry | ||
Element |
Min |
max |
C |
0.07 |
0.12 |
Mn |
1.70 |
2.30 |
Si |
|
0.60 |
P |
|
0.010 |
S |
|
0.010 |
Ni |
14.00 |
21.00 |
Cr |
19.00 |
21.00 |
Co |
39.00 |
41.00 |
Mo |
6.50 |
7.50 |
Fe |
balance |
Balance |
Physical property | |
Item |
Target |
Modulus of Elasticity E/Mpa |
196000~215500 |
Shear Modulus G/Mpa |
73500~83500 |
Density (g/cm3) |
8.4 |
Mean coefficient of linear expansion20-100°C/(10-6/K) |
14 |
Resistivity ρ /(μΩ•m) |
0.29 |
Magnetic Rate k/106 |
50~1000 |
Remark:The K value is the centimeter gram second system
Mechanical property | ||||
shape |
Delivery state |
Thickness&diameter |
Tensile strength(ób/Mpa) |
Elongation δ(%)≥ |
sheet |
Cold rolling |
0.20-2.50 |
1175~1470 |
5 |
1470~1765 |
3 |
|||
wire |
Cold dawn |
0.20-5.00 |
1275~1570 |
--- |
1570~1865 |
---- |
|||
Size range | |
Thickness:0.10mm~2.50mm, width:10.0~210mm,Condition: cold rolled, bright, | |
Dia 0.1mm~Dia 7.0mm,Condition: cold drawn, bright | |
Dia 7.0mm~Dia 10.0mm,length:≤2000mm,Condition:cold drawn, bright | |
Specification | ||
Sheet |
Rod |
wire |
APPLICATION |
It is applied to make antimagnetic,corrosion-proof and long range elasticity alloy for elastic cell. |
According the characteristic of material ,suitable packing and follow China Customs regulations, or As buyer's request .
Delivery items are flexiable , Shipping, Air lift ,train , hight speed ground transportation ,ect
1, sample free
2, faster delivery
3, helpful staff
4, quick response
6, testing before shipping
7, We will reply you for your inquiry in 24 hours.
8, advanced facilities
9. technical support
10.No min order request
XAGY Inc was establish in 1993, with a company mission to provide a high qulity, reliable source for precision alloy and high temperature alloys in both scientific research and production . This mission continues today, after more than twenty-three years.
XAGY Inc, continuing goal is to supply high quality products, service, and support to our customers at competitive prices. Our factory flexibility enables prompt response to any customer's unique needs. We can ship orders faster, you will always be greeted by a competent sales representative during business hours when you call...or email .
The factory was certified by the ISO9001-2008 quality system in June 2005 and it was certified as high-tech factory by Shaanxi Provincial Department of Science & Technology. In same year ,Shaanxi Provincial Development and Reform Commission identified the major businesses of the company as the industries that the country mainly encourages and develops.
Throughout our 23+ years of service we have come to be a valued resource for precision alloy for domestic and international manufacturing companies and worldwide, as well as most china government. To pursue excellent and surpass oneself is what XAGY Inc has been striving for. We always follow the principle of "quality and technology first, sincere service and observing the contract" and try our best to develop XAGY Inc into a metallica functional material manufacturer with core competitiveness and continuous capabilities of growth so as to provide all our customers with more and better services and products.
