Low expansion and high quality Invar alloy
- 6000 Ton / Tons per Month
- GuangZhou
You May Like
Product Details
Place of Origin | Shaanxi, China | Type | Nickel Bar | |
Application | Electronic Instrument | Grade | Ni+Fe+co | |
Ni (Min) | 36% | Powder Or Not | Not Powder | |
Model Number | 36 alloy | Brand Name | XAGY |
Product Description
Invar (also know as Invar 36, NILO 36, Pernifer 36, and Invar Steel) is a low expansion alloy consisting of 36% Nickel, balance Iron. Invar Alloy exhibits extremely low expansion around ambient temperatures, making Invar Alloy particularly useful in applications where minimum thermal expansion and high dimensional stability is required, such as in precision instruments like optoelectronic devices, optical and laser benches, electronics, and other kinds of scientific instruments.
Invar alloy chemistry | |||
Element | Min(%) | Max(%) | |
C |
| 0.05 | |
SI |
| 0.30 | |
P |
| 0.020 | |
S |
| 0.020 | |
NI | 35.0 | 37.0 | |
Mu | 0.20- | 0.60 | |
FE | balance |
Notes:under condition that the average coefficient of the linear expansion meets the requirements of the standard,
the content of nickel and cobalt are allowed to deviate from the stated range.
Physical Properties | ||
Density | lb/cu in | 0.291 |
Specific Gravity |
| 0.825 |
Curie Temp
| °F | 535 |
°C | 279 | |
Melting Point
| °F | 2600 |
°C | 1427 | |
Electrical Resistivity | Micro-ohm-cm | 84 |
Micro-ohm-cm | 495 | |
Thermal Conductivity | W/cm °C | 0.10 |
BTU-in/sq. ft-hr- | 72.6 | |
Specific Heat | Cal/g- °C | 0.123 |
BTU/lbm- °F | 0.123 |
Coefficient of linear expansion | |
20---50℃ | 0.6 |
20--100℃ | 0.8 |
20--200℃ | 2.0 |
20--300℃ | 5.0 |
20---400℃ | 8.0 |
20---500℃ | 10.0 |
Size Range | |
Sheet | Thickness 0.1mm---3.5mm, width:≤300mm |
plate | Thickness 3.5mm---40.0mm,width:≤300mm |
wire | Dia 0.1mm----Dia 5.0mm |
rod | Dia 8.0mm,length:≤2000mm Dia 8.0mm-----Dia 32.0mm,length:≤2500mm Dia 32.0mm------Dia 180.0mm,length:≤1300mm |
1. sample free
2, faster delivery
3, helpful staff
4, quick response
6, testing before shipping
7, We will reply you for your inquiry in 24 hours.
8, advanced facilities
9. technical support
XAGY Inc, was establish in 1993, with a company mission to provide a high qulity, reliable source for precision alloy and high temperature alloys in both scientific research and production . This mission continues today, after more than twenty-three years.
XAGY Inc, continuing goal is to supply high quality products, service, and support to our customers at competitive prices. Our factory flexibility enables prompt response to any customer's unique needs. We can ship orders faster, you will always be greeted by a competent sales representative during business hours when you call...or email .
The factory was certified by the ISO9001-2008 quality system in June 2005 and it was certified as high-tech factory by Shaanxi Provincial Department of Science & Technology. In same year ,Shaanxi Provincial Development and Reform Commission identified the major businesses of the company as the industries that the country mainly encourages and develops.
Throughout our 23+ years of service we have come to be a valued resource for precision alloy for domestic and international manufacturing companies and worldwide, as well as most china government. To pursue excellent and surpass oneself is what XAGY Inc has been striving for. We always follow the principle of "quality and technology first, sincere service and observing the contract" and try our best to develop XAGY Inc into a metallica functional material manufacturer with core competitiveness and continuous capabilities of growth so as to provide all our customers with more and better services and products.
