Home > Manufacturing & Processing Machinery > Plastic Machinery > Plastic Granulator > Manure Organic Fertilizer Pellet Making Machine (CE) Quality Choice
Manure Organic Fertilizer Pellet Making Machine (CE) Quality Choice
US$ 880 - 99,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Product Type:
Other, Fertilizer, Fertilizer
Place of Origin:
Shandong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
SKJ2-300 Fertilizer Pellet Mill SetupUS$ 1,500 - 60,000MOQ: 1 Set -
Fertilizer Making Machine (CE)US$ 880 - 99,000MOQ: 1 Set
-
Fertilizer Making Equipments (CE)US$ 880 - 99,000MOQ: 1 Set
-
SKJ3-550 Fertilizer GranulatorUS$ 1,500 - 60,000MOQ: 1 Set
-
Organic Fertilizer Pellet MillUS$ 1,500 - 60,000MOQ: 1 Set
Condition
New
Product Type
Other, Fertilizer, Fertilizer
Place of Origin
Shandong, China
Brand Name
YULONG
Model Number
SKJ3-550
Voltage
Any
Power(W)
90kw
Dimension(L*W*H)
2350x1000x2050mm
Weight
5.5 ton
Certification
CE,ISO9001:2008,SGS
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
manure organic fertilizer pellet making machinefertilizer: 2-8mm dia,ball or cylindrical granules
manure,dung,humic acid,etc
Manure organic fertilizer pellet press/ pellet making machine:
anic fertilizer pellet press adopt taper shape, which makes their ends rounding linear speed consistent with flat die, so it avoid dislocated friction which maybe created between rollers and die. In this way, it can reduce friction and save much energy consumption, lengthen die and rollers life. This is significant difference between the similar compression formation machinery.
2.Fertilizer pellet mill advantage one: rollers being enlarged, the bearing enlarged, so it can withstand bigger standing ability.
3.Advantage two: roller being enlarged, the temperature caused by extrusion friction not to be easy to transmit the bearing room to guarantee the bearing work in the low temperature and the lubrication grease not easy to overflow.
4.Advantage three: rollers being enlarged, rollers can be repaired 2-3 times, the lifetime is longer, so that the production cost is reduced, and the project profit space is enlarged.
5.This type compression formation is varied, pellets or granules can be adjust by changed the dies. Adapting to difference material to achieve maximum effectiveness.
anic fertilizer pellet press adopt taper shape, which makes their ends rounding linear speed consistent with flat die, so it avoid dislocated friction which maybe created between rollers and die. In this way, it can reduce friction and save much energy consumption, lengthen die and rollers life. This is significant difference between the similar compression formation machinery.
2.Fertilizer pellet mill advantage one: rollers being enlarged, the bearing enlarged, so it can withstand bigger standing ability.
3.Advantage two: roller being enlarged, the temperature caused by extrusion friction not to be easy to transmit the bearing room to guarantee the bearing work in the low temperature and the lubrication grease not easy to overflow.
4.Advantage three: rollers being enlarged, rollers can be repaired 2-3 times, the lifetime is longer, so that the production cost is reduced, and the project profit space is enlarged.
5.This type compression formation is varied, pellets or granules can be adjust by changed the dies. Adapting to difference material to achieve maximum effectiveness.
Pelleting store is equipment with observation door, it is convenient inspect or maintenance at any time.
Application scope:
Fertilizer pellet mill is the special equipment for making organic fertilizer. It is mainly applied to animal manure, home wastage, sludge, peat and so on pelletizing.
Technical parameters:
Technical parameters:
| model | Output(t/h) | Power(kw) | Specification(mm) | Weight(t) | Size(mm) |
| SKJ3-350 | 0.6-1 | 37-4 | φ4.5-10 | 2.2 | 1900×850×1750 |
| SKJ3-450 | 1-1.5 | 45/55-4 | φ4.5-10 | 4.3 | 2300×1100×1900 |
| SKJ3-550 | 2-3 | 75/90-6 | φ4.5-12 | 5.5 | 2350×1000×2050 |
| SKJ3-800 | 3-5 | 130-160 | φ4.5-12 | 6.8 | 3200×1235×2700 |
| SKJ4-1200 | 5-8 | 280-320 | φ4.5-15 | 19 | 3800×1700×4200 |
Best regards
Ruby shao
Zhangqiu Yulong Machine Co., Ltd
Tell: 0086-531-83483997
Fax: 0086-531-83483378
Mobile: 0086-18678866205
