Specifications
Organic fertilizer pellet machine1)CE,ISO certificate
2)round shape ball pellet
3)high capacity and low investment
fertilizer pellet machine
fertilizer pellet machine Working Principle
WLZL series horizontal centrifugal granulator adopts clicking drive rotary feeding principle, with new concept, unique and complex design process, centrifugal force to the powder material which in cylinder tank , the powder material would adhesive to spherical pellets under the action of centrifugal force.
Characteristics
1.This type fertilizer pellet machine adopts the centrifugal rotational, friction and adhesion, polishing shape, friction heat drying to three machine unity granulation process, completely instead of the previous huge investment, complex craft, repetition of traditional process.
2. fertilizer pellet machine Adopts centrifugal adhesive, rolling form technology, no need mould pelletizing, so the processing cost is low and efficiency is high.
3. fertilizer pellet machine Pellets well-distributed, smooth, rounded, high intensity, good liquidity, pellet formation rate above 95%.
4. The temperature of the cylinder tank reach 60-120 during the material centrifugal friction, heat drying and adhesion forming process, granulation process is also same drying process, reducing the drying cost.
5. fertilizer pellet machine Equipment with less investment, lower operating cost.
fertilizer pellet machine Technical parameter:
Model |
Power(KW) |
Diameter(mm) |
Length(mm) |
Capacity(T/H) |
WLZL600 |
45 |
630 |
4400 |
0.8-1.5 |
WLZL800 |
75 |
820 |
4500 |
1.5-3 |
WLZL1000 |
110 |
1020 |
4500 |
2.5-4 |
WLZL1200 |
132 |
1220 |
4500 |
3.5-5 |
WLZL1400 |
160 |
1420 |
4500 |
5-8 |
Mr Jerry Wang
Mobile: 86-18678866200
SKYPE: jerryjerry1044
ZHANGQIU YULONG MACHINE CO.,LTD
Biomass Pellet Mill:
Feed Pellet Machine:
Fertilizer Pellet Press: www.
fertilizer pellet machine pics
