automatic rice production machine 60-100kgs/hour

Specifications

rice production machine
1. twin screw extruder
2. Flakes, cereals, snacks
3. Corn flour as raw material
4.380v/50v

   automatic rice production machine 60-100kgs/hour

nical parameter

Model Parameter	DS56-III Line	DL70-II Line	DL85-II Line
Input voltage	380V,50Hz,	380V,50Hz,	380V,50Hz,3 phase 4 line
Installed power	118kw	204kw	234kw
Real power consumption	88kw	160kw	180kw
output	120-150kg/h	180-220kg/h	300-500kg/h
length	46m	50m	66m

General introduction for the processing line

This processing line is very easy to handle.From mixing,puffing,cutting and shaping,drying,and flavoring. You can take wheat flour,corn flaour,rice powder,and other cereals as raw material,which canbe mixing with water in the mixer.

Mixing: put the raw materials in the mixing machine, add amount of water according to the proporty of materials.and wait for one minnute.



Extruding:  the thoery of extruder is using high temperature and high pressure to puffing the materials.when the extrudate out the extruder, the hign pressure and temperature transform to ordinary pressure and temperature.So the water will  evaporate quickly meanwhile, the textile of food is changed.



Cutting and shaping: the cutting and shaping stand after the extruder, the extrudate comes out from extruder to the cutting and shaping machine,  you can change the length by adjusing the cutting speed. The shorter the food, the quicker the speed. meanwhile, by changing a shaping die,we can change another shape. our company can offer many kinds of shapes to meet you demand.



Drying: after shaping, we need a dryer to cook the food. one reason is to lengthen the life of food, another is to make food more crispy. we normally set the temperature 160'C-180'C.



Flavoring: our company using rolling methods to seasoning. the flavoring materials can be powder or liquid. meanwhile, there is a oil spraying machine with the seasoner.
