1-2t/h rice husk fuel pellets making line for sale

suitable for sea transport(1-2t/h rice husk fuel pellets making line)

Specifications

wood complete pellet line
1.low price, high quality
2.CE,SGS,ISO9001 approved
3.rich installation experience

YULONG brand complete pellet line is 1-2t/h rice husk fuel pellets making line to make pellet from any type of agro-forestry wastes with output 0.7-1t/h; 1-1.5t/h; 1.5-2t/h; 2-3t/h; 3-4t/h; 5-6t/h; 7-8t/h.

Pelletizing is the process of making waste materials into solid fuel. The objects are used for burning purposes. Wood pellet can be made from any type of agro-forestry waste: groundnut shell, sugarcane bio-gases, caster shells/stalk, saw dust, coffee husk, paddy straw, sunflower stalk, cotton stalks, tobacco waste mustard stalk, jute waste, bamboo dust, tea waste, wheat straw, palm husk, soybeans husk, coir pitch barks/straws, rice husks, forestry wastes, wood chips and many other agro wastes.



Patameter of 1-2t/h rice husk fuel pellets making line

Raw material	Suitable for low adhesion rate, such as rice husk, palm fiber, sunflower husk, peanut and fruit shell;  wood wast, such as brand, stem, bark; all kinds of crop stalks;  and other chemical materials, such as rubber, cement, ash.
The moisture of  raw material	15-20% suitable to press pellet
Capacity	1.7-8t/h
Main parts	Crusher, dryer, pelletizer, cooler and packing
Key parts	Pelletizing
model	Capacity(t/h)	Power(kw)	Pellet dia(mm)	Weight(t)	Size(mm)
XGJ550	0.7-1	75	4-12mm	6.04	2630*100*2400
XGJ560	1-1.5	90	4-12mm	6.1	2600*1300*2300
XGJ580	1.5-2	160	4-12mm	7	2900*1300*2400
XGJ850	2-3	220	4-12mm	14.5	3300*1400*3100
XGJ880	3-4	315	4-12mm	18	3800*1680*3400
XGJ1050	5-6	360-450	4-30mm
XGJ1250	7-8	550-660	4-30mm



1. Crushing Process:
Depending on the different input material, we fit out the suitable Crushing machines. If the raw material is the Straw Baler, we developed the series hammer mill. If the raw material is big logs with diameter less 300mm or big timber cutter, our wood chipper is your best choices, the chips is 1-3cm, than you can use a hammer mill to be sawdust. the size of sawdust should be smaller than the size of finished pellet dia.



2. Drying Process:

The best moisture content to pelletizing is about 15-20%. we select dryer according to your raw material, if your raw material is small, light and easy to dry, we will recommend you our air-flow dryer; and if your raw material is big, not light and hard to dry, we will select our rotary dryer for you. about the hot air stove, you can burn fuel, such as wood, sawdust and so on.



3. Pelletizing Process:
XGJ series wood pellet machine is our patent product which has adopted the essence of pellet machine in oversea market. The heart parts"double layer die" has unique structural assembly and "rollers"are made of high wearable alloy materials, and they are with low energy, high efficiency, long life and so on. XGJ series new type pellet machine has filled the country blank in vertical feeding for ring die pellet mill and reached the international advanced level.



4. Cooling Process:
After the pelletizing process, the temperature of the wood pellet is about 60-80 degree, and the moisture content of the wood pellet is about 15%, so we need use Cooler to reduce about 3-4% moisture, such this the wood pellet is easy to store.





5. Packing Process:
After cooling, the wood pellet will not directly enter into the fuel process, avoiding the wood pellet affected with damp. The packing process is necessary. we have two kinds of packing machine, one kind is heat sealer, the other one is automatic seam, according to your requirement.



1-2t/h rice husk fuel pellets making line contact information

Ms. Mary Wang

Mobile:18678866216

Skype:marywang0103

ZHANGQIU YULONG MACHINE CO.,LTD

Biomass Pellet Mill:

Feed Pellet Machine:

Fertilizer Pellet Press:



FAQ about 1-2t/h rice husk fuel pellets making line

1. Are you a factory or a trade company?

ZHANGQIU YULONG MACHINE CO., LTD is a factory experting in makine biomass pellet making equipment all over the world for more than 16 years, we have agent in Thailand, Poland, and Bulgaria. we also have our owner patent production, XGJ series pellet machine.

2. Can you help us instal the biomass pellet making equipment?

Yes, we can. we will send 2-3 person to instal the equipment, and they will teach you daily maintenance and maintenance.

3.What is your delivery time?

Different production line has different delievery time, but general about 60 days.



In order to recomment the most suitable production line to you, so kindly let me know

1)what is your raw material? how about the size of your raw material?

2)what is your raw material's moisture?

3)what capacity do you need?

4)what is the voltage in your country? is 380v,50Hz,3 phases fine for you?
