Help CenterSmall Sawdust Dryer (CE)
Related Products
Specifications
-small sawdust dryer fit for wood sawdust, wood chips, palm fiber-high efficient, with CE, ISO9001:2008
- low rotary speed
Drum dryer system:
we produce two kinds of dryer machine: rotary dryer and air-lock dryer.
Our dryer machine approved CE certificate and ISO9001:2008 certificate.
out rotary dryer machine reduce the water content through the hot air from the stove,make the big moisture decrease the low moisture, until the materials can be further used.
The dryer system including feeder, drum, fan blower, cyclone, air-lock, outlet conveyor and stove, the evaporate Quantity of the dryer can be larger by lengthening the machine .It depends on your request.
Rotary dryer adopts low-speed rotarying,curved plate hammering ,dispersing raw material ,making the high-temperature air flow current mixed with raw material ,so that we can achieve the drying goal.
It mainly applied to drying process of all kinds of powder raw material, such as wood sawdust, wood chips, palm fiber, the crop stalks and straw pieces,animal waste, household waste and so on.It can be widely used in the fuel factory ,fertilizer factory ,chemical factory ,medicine factory and so on .
Model |
Diameter (mm) |
Length (mm) |
Power (kw) |
Evaporation Capacity (t/h) |
Inlet temperature |
Outlet temperature |
Weight (kg) |
GHG1.0X10m |
1000 |
10000 |
5.5 |
0.3-0.4 |
180~700°C |
70~90°C |
2960 |
GHG1.4X10m |
1400 |
10000 |
7.5 |
0.5-0.6 |
4143 |
||
GHG1.5X12m |
1500 |
14000 |
7.5 |
0.6-0.8 |
5327 |
||
GHG1.6X24m |
1600 |
12000 |
15 |
0.8-1 |
11364 |
||
GHG1.8X24m |
1800 |
15000 |
18.5 |
1-1.1 |
12785 |
||
Note: Wood pellets,wood chips, coal and wood waste material as the fuel burnt in stove. | |||||||
