IBZ BX Series Semi-mounted Heavy-duty Disc Harrow
Negotiable
MOQ: 5 Sets (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
China
Model Number:
IBZ BX Series
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
China
Model Number
IBZ BX Series
Specifications
We can supply disc harrow, disc plough and related parts.The machine is suitable for crushing and cleaning crop residues on the virgin land and heavy clay soil before tillage and crushing soil clods after tillage. On the cultivated land, it can be used as the plough for the initial cultivation and the harrowing depth can be 180mm max. After harrow, the land surface is smooth and the soil clods and crop residues are well crushed. It is easy to be mounted and adjusted, reverse freely, and convenient for transportation.
Model |
1BZ(BX)-2.0 |
1BZ(BX)-2.5 |
1BZ(BX)-3.0 |
Working width(m) |
2.0 |
2.5 |
3.0 |
Qty of disc |
20 |
24 |
28 |
Disc diameter(mm) |
660 |
660 |
660 |
Working depth(mm) |
180~200 |
180~200 |
180~200 |
Overall weight(kg) |
1050 |
1200 |
1350 |
Fitted power(KW) |
53~58.8 |
58.8~73.5 |
58.8~88 |
Linkage |
Semi-mounted |
||
