Help Center1BJX Series of Mounted Medium Disc Harrow
Related Products
Specifications
We can supply disc harrow, disc plough and related parts.1BJX series of mounted medium disc harrow
The machine is suitable for pulverizing and loosening clods after plowing and for planning the land before sowing on cultivated land, it can make soil and fertilizer mix up, and clean away the stump of plants. With the reasonable structure, the machine is durable in service, easy to be operated and maintained, the land surface is smooth.
Model 1BJ-4.4 with 40 discs folded wing middle-duty disc harrow is suitable for operation on middle and light soil as harrowing instead of plowing, loosening soil before sowing, cleaning residues of crops and weeds. The machine has the merits of high efficiency and reasonable utilization of the power, well ability of crushing soil, working width is wide and transportation width is narrower, etc. It is easy to be mounted and adjusted, reverse freely, and convenient for transportation.
Item |
1BJX-1.8 |
1BJX-2.0 |
1BJX-2.2 |
1BJX-2.4 |
1BJX-2.5 |
1BJ-4.4 |
Overall dimension (cm)L*W*H |
1850*201*132 |
198*224*132 |
198*247*132 |
278*247*132 |
297*268*146 |
542*432*113 |
|
Working width(m) |
1.8 |
2.0 |
2.2 |
2.4 |
2.5 |
4.4 |
|
Working depth(m) |
140 |
140 |
140 |
140 |
140 |
140 |
Qty of disc |
16 |
18 |
20 |
22 |
24 |
40 |
Disc dinameter(mm) |
560(610) |
560(610) |
560(610) |
560(610) |
560(610) |
560(610) |
Overall weight(kg) |
390 |
434 |
463 |
604 |
760 |
1750 |
Fitted power(kw) |
33 |
37~44 |
37~47.8 |
47.8 |
54.9 |
55-73.5 |
Linkage |
Standard three-point mounted |
Traied |
||||
