HSY-R131 RFID Scanner Door Access Card Keytag Reader Proximity External Reader Controller

 HSY-R131 RFID scanner door access card keytag reader proximity external reader controller

Advantage:

1.16 years experience professional in RFID products

2. OEM/ODM orders are welcome;

3. Professional techniques supports;

4. Best quality,Best price,Best Service.

RFID card reader is a standard Wiegand26 bit output format and an off-contact high performance reader. Its main use is as a supplementary reading device for the controller which has the wiegand interface. It characters with exquisite appearance, convenient installation and stable characteristics.

Door access card keytag reader Specification:

Door access card keytag reader Sample shows:

Installation:

Using “+”type screw driver to loosen the screw between the panel and motherboard. And then embed the motherboard to the side wall with the plastic plug and screws.

Notice!!!

1. Confirm the electric voltage (DC12V) and differentiate positive anode and cathode of power supply

2. When external Power is used, make sure sharing the power with Controller Box or using the same GND

3. The wire connects reader to controller, advise use 8 cores stranded twisted pair cable(among them, three strands are spare, if no need reader show illegal card s by sound and light, LED wire can not be used, data wire Data1 Data0 are twisted pair would be better, we suggest sectional area are 0.22 square millimeter at least. The length should not exceed 100meters.

Packaging & Shipping



Shipping :

1. FedEx/DHL/UPS/TNT for samples, Door-to-Door service;

2. By Air or by Sea for bulk goods, for FCL; Airport/ Port receiving;

3. Support Customers specifying freight forwarders or selected shipping methods!

4. Delivery Time: 2~7 working days. Accurate deliver based on your quantity .
