4 Doors 4 RFID Readers 4 Buttons SDK Software Wiegand Access Control Board

 HSY-04 4 Doors 4 RFID Readers 4 Buttons SDK Software Wiegand Access Control Board

Access Systems are built on flexible, open technology to provide management, real-time monitoring ,

and control of your access control system—all from a browser, with no additional software to install.

Our secure Web-hosted infrastructure and centralized online administration reduce your IT costs and

allow you to easily manage all of your access points in a single location. can communicate at

Ethernet TCP/IP networks.

It can store up to 10,000 cardholders.

Features :

HSY-04 is now capable to handle 4 doors / 4 readers.

1. 10,000 cards and 30,000 offline records.

2. Wiegand input metal case power supply.

3. Have SDK and software.

4. Support password mode, realizing card and password double authentification.

5. Data memory function, back-up battery can ensure the terminal working without power.

6. Web base( Browser/ server ) software with complete.

7. Basic function setting : Door Sensor Alarm, first card setting, time one, double door linkage, threaten password, door often-open status setting, anti-pass back, electronic map, remote control real time monitor.

4 door Access control panel Specification:

Access control panel photos:

Optional metal case power supply:

Attention:

1. Wiring standard:

      Even the connection distance is very short, is must be implemented according to the following requirement

2. 220V AC power cable:

      Three- wire power supply,the cross-sectional area 1.0  square or more.It's required that power supply must be grounded to prevent from power interference

3. The line of electric lock to controller:

    It's recommended to use two-wire power line,the cross-sectional aera 1.0  square or more. if the distance over 50meter,it's considered to use thicker line or multiple paraller.

4. TCP/IP communication line: Network cable

5. The card reader, door sensor and button line:

       Can use network cable or others.

Packaging & Shipping

 1pcs per box,control board 0.5kgs only,
together with metal case power supply around 4kgs per unit.



Shipping :

1. FedEx/DHL/UPS/TNT for samples, Door-to-Door service;

2. By Air or by Sea for bulk goods, for FCL; Airport/ Port receiving;

3. Support Customers specifying freight forwarders or selected shipping methods!

4. Delivery Time: 2~7 working days. Accurate deliver based on your quantity .
