HSY-F5C RFID system hardware and software Networked RFID reader for access control
HSY-F5C Features:
Strictly follow the national security product standard. Suitable for the entrances and exits of apartment, multi-family houses, office, factory, hotel, school, etc.
TCP/IP + RS485 Communication + USB Flash Drive Up/Download.
Anti-dismantlement alarm, threatens alarm, unlock illegally alarm, not block alarm are available.
Fingerprint / Card / Password / Fingerprint + Card / Fingerprint + Password / Card + Password / Fingerprint + Card + Password identification modes are all available.
Networked RFID reader Spec:
| Model | HSY-F5C |
| Color display | Yes |
| Fingerprint Sensor Resolution | 500DPI |
| Rotational Angle | Total Rotational Angle |
| FRR | ≤0.1% |
| FAR | ≤0.0001% |
| Identification Time | ≤0.1 S |
| Query Record | Available |
| Real Time Fingerprint Picture Display | Available |
| Operating Mode | Off-line/On-line |
| Authentication Mode | 1:1; 1:N |
| Identification Mode | Fingerprint/ID Card/Password |
| Fingerprint Capacity | 2,000 |
| Log Capacity | 50,000 events |
| Communication | TCP/IP, RS485 |
| U disk up/download | Available |
| Language | Chinese, English, Korean |
| Voice prompt | Available |
| Capacity notification | Alarm when log capacity is full |
| Bell | Built-in timing bell |
| Lock Output | Normal Open / Normal Closed |
| Door Open Button | Can connect the common button, or the wireless remote controlled button |
| Doorbell Output | Can connect the doorbell in every voltages |
| Access Control Interface | Wiegand 26/34 Optional, Input/ Output Optional |
| Anti-pass back | Available |
| Alarm | Threatens Alarm, Anti-dismantlement Alarm, Unlock Illegally Alarm, Circumscribed Alarm, Time-out Alarm |
| Power | DC 12V/1A |
| Operating environment | Operating Temp: 0°C-50°C, Humidity:80% |
| Size of the Terminal | 181(L)*91(W)*36(H)mm |
Networked RFID reader Sample:
Menu Screen:
Introduction:
Setting Device Menu:
More information overview:
1. FedEx/DHL/UPS/TNT for samples, Door-to-Door service;
2. By Air or by Sea for bulk goods, for FCL; Airport/ Port receiving;
3. Support Customers specifying freight forwarders or selected shipping methods!
4. Delivery Time: 2~7 working days. Accurate deliver based on your quantity .
Company & Certification :
FAQ:
Q1: What is the Warranty for products ?
A1: We have Professional technical Departments,Our Warranty:1 years' product warranty, A lifetime technical support .
Q2: How to make payment ?
A2: We can accept transfer by T/T, Paypal, Westerm Union and Escrow.
Q3: What is MOQ and price ?
A3: We support sample and bulk order, Will offer best price based on your order.
Q4: Do you support after-sales service ?
A4: Yes, we have an international professional team offer 24h*7 after-sales service.
