7.8 "STN Digital Storage Oscilloscope (with 40M)

Name: 7.8 "STN Digital Storage Oscilloscope (with 40M)
Brand: Kangput
SKU: 100927751
Availability: InStock

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Fujian, China

Brand Name:

Kangput

Model Number:

EDU6042S

Xiamen KANGPUT Electronics Technology Co., Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Fujian, China

Brand Name Kangput

Model Number EDU6042S

7.8 "STN digital storage oscilloscope (with 40M)

Model:EDU6042S

Model	KangPut EDU6042S 7.8 " STN digital storage oscilloscope (with 40M)
Function	7.8 "STN popular type of digital storage oscilloscope; With 40M bandwidth, 250M S/s realtime sample rate on each and dual channels storage ;large screen color STN LCD display, applied to basic education needs more water to meet the production line of electronic detection. Automatically trigger a variety show that the stability of any information wave. On the screen shows a substantial value or more of each other coverage of the wave.
Specification	Bandwidth	40MHz
	Real-time sampling rate	250MS/s
	Rise time	≤8.75ns
	Channels	2+External
	Record length	5K points per channel
	Time base scope	5ns/div -5s/div
	Vertical sensitivity	5mV/div -5V/div
	Displacement	±10div	±50V(500mV--5V), ±2V(5mV--200mV)
	Trigger modes	Auto,Normal,Single,Edge,Video,Alternate
	Scope measurements	2 Cursor+5 Automatic
	Max Input Voltage	300V (PK-PK)CAT II
	Input Coupling	AC,DC
	Input Impedance	1MΩ±2% in parallel with 20pF±5 pF
	Probe attenuation factors	1X,10X,100X,1000X
	Vertical resolution	8 bit
	Time Base Accuracy	100ppm
	Memory for screen and set up	4 waveforms, 4 settings
Other	Power supply	100-240 V AC,50Hz-60 Hz,CAT II
	PC interface	RS232 cable or USB cable
	Display type	7.8inch color STN LCD
	Display Resolution	640 ×480
	Dimension	350mm × 157mm × 120mm
	Weight	1kg
