16ch Standard Alone DVR

Name: 16ch Standard Alone DVR
Brand: Bellsent
SKU: 100918217
Availability: InStock

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Bellsent

Model Number:

DVRBE-8516-H

Shenzhen Bellsent Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Bellsent

Model Number DVRBE-8516-H

Specifications

Stand-Alone DVR, H.264 Compression
High quality video Display : NTSC (720x480),
PAL (704x576) real time display

FEATURES:

• Stand-Alone DVR, H.264 Compression

• High quality video Display : NTSC (720x480),

PAL (704x576) real time display

• Multiple Recording/ Search Categories:

Date/Time, Event, Manual, Schedule,alarm, motion detection

• Real time recording support:

480 Fps for NTSC at CIF image (400 Fps for PAL)

• 16ch Video recording at the same time

• Pentaplex: Live, Record, Playback, Back-up and Network at the same time

• Backup: CD-RW (Option: DVD-RW), USB 2.0 and NET backup supported

• PTZ camera control in local and remote area with 256 positions cruise

Network Viewer

• Static, Dynamic IP and DDNS , Support Internet Explorer and special client software

• Remote Live Monitoring, file searching, Backup, Playback and PTZ camera control

• Remote Configuration, Firmware Upgrade and Event (Alarm, Motion) Notification

• Mobile monitoring and E-mail notification

• Mobile monitoring (3G) and E-mail notification

Items	Specifications
Model Name	DVRBE-8516H
Compression Standard	H.264
Resolution	Preview resolution:704 x 576 ( PAL ) , 720 x 480 ( NTSC ) Playback resolution:16 x CIF Frames:1F/S ~ 30F/S (Adjustable)
Hard Disk	2 SATA Hard Disk interface (Support Capacity from 40G to 3T in Total )
Video Input	16 channel, BNC , 1.0V p-p/75Ω
Composite Video Output	1 channel, BNC, 1.0V p-p/75Ω
VGA Interface	1 VGA, Resolution: 800x600, 1024x768, 1280x1024, 1024x600 optional
Audio Input	2 ch
Audio Output	2 ch
Alarm Input	4 Channel, Trigger closed without Voltage,Open or Closed
Alarm Output	1 Channel, Trigger closed without Voltage,Open or Closed
Alarm Mode	Sensor Input, Motion Detection, Video Loss, Full Disk Space.
Network	Ethernet (10/100M ),LAN,WAN and ADSL
Control Way	USB2.0 Mouse, Remote Control, PTZ, Camera, RS485 x 1
Backup	USB2.0, CDRW, DVDRW and Network
Bit Rate	Main Stream : 5 Levels optional :120MB/H ~ 500MB/H and self-defined Secondary Stream: 5 Levels optional : 20MB/H ~ 140MB/H and self-defined
Password	Encrypted by 128-bit Numerical Digits with 2-Level Password Protection
Power Supply	DC12V 3.0A
Consumption	20W(Without HDD)
Working Environment	Temperature: +5°C~+50°C; Humid:< 90%
Device Dimension	350×272 X 58 mm (WDH)
Weight	N.W: 2.4KG G.W: 3.8KG
