Home > Lights & Lighting > LED Encapsulation Series > LED Module > Waterproof Cree LED Module 5730,90lm/W Cree Led Module 12V
Waterproof Cree LED Module 5730,90lm/W Cree Led Module 12V
US$ 0.2 - 3
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Model Number:
BW-MD5001
Chip Material:
Other, PVC, ABS PLASTIC
Emitting Color:
Cool White
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Led Module String for Led Backlight Sign BoardUS$ 0.8 - 5MOQ: 100 Pieces -
White SMD 5050 DC12V 4 Chips SMD LED Module WaterproofUS$ 0.6 - 4MOQ: 100 Pieces
-
Hot Sale !!! Outdoor Single Color Led Display ModuleUS$ 0.8 - 5MOQ: 100 Pieces
-
Led Light Module for Greeting Card / 5730 Led Module for Signs New ProductsUS$ 0.8 - 5MOQ: 100 Pieces
-
Shenzhen Wholesale Led Modules 3 Leds New Led ModulesUS$ 0.2 - 3MOQ: 100 Pieces
Model Number
BW-MD5001
Chip Material
Other, PVC, ABS PLASTIC
Emitting Color
Cool White
Luminous Intensity
92
Luminous Flux(lm)
110
Optical Attenuation(%)
1
Power
Other, 1.2
Power Dissipation
1.3
Color Rendering Index(Ra)
80
Color Temperature
2700K,4500K,6000K
Operating Temperature(℃)
-20, 50
Storage Temperature(℃)
-20, 60
Place of Origin
Guangdong, China
Brand Name
Brightway LED Limited
Certification
CE
Specifications
Cree LED Module1 Led module IP65
2 High Brightness LED module
3 Channel letter sign LED back light
4 2/3/4 LED,DC12V
Waterproof cree LED Module 5730,90lm/W Cree led Module 12V
LED Module Introduction:
1,Injection Module adopts ABS material as its shell. transparent epoxy resin around the lights with good insulativity.
2,Comprehensive performance , good with excellent electrical performance, impact strength and wear resistance, chemical resistance, moisturecontent , shaping and excellent machining technology.
3,Completed through injection in one time. solves the problem that nonuniform sealing, dirty shell and LED stand out of the glue etc. It is simple artwork with good appearance and short lead time as well.
4,Good cold resistant available for -20~40°C. 3M adhesive tape and screws for customers to fix it in easy installation.
LED Module Details:
| Part No. | Color | LED chip | LED Qty (pcs) | Input Volt | Power (watt) | Lumens | Viewing angle | IP Rank |
| BW-MD1001 | Pure white Warm white Red Green Blue Yellow | SMD3528 | 3 | DC 12 | 0.3 | 24LM | 140° | IP65 |
| BW-MD1002 | SMD5050 | 3 | 0.72 | 48LM | ||||
| BW-MD1003 | SMD5050 | 4 | 1.2 | 64LM | ||||
| BW-MD5001 | Pure white Neutral white Warm white | SMD5730 | 3 | 1.2 | 110LM | |||
| BW-MD5002 | SMD5730 | 2 | 1.2 | 85LM | ||||
| BW-MD5003 | SMD5730 | 3 | 1.2 | 110LM | ||||
| BW-MD6001 | CREE XP-E | 1 | 1.3 | 95LM |
LED Module Features:
1. Unique design, ABS PLASTIC Molding shell, adopting high brightness S,3528 SMD5050 SMD5730.
2. High llighting efficiency which can reach 90lm/W.
3. IP Rand: IP65.
4. Adopting with DC12V constant voltage driver.
5. With retrofitted holes and 3M tape, two installation choice.
LED Module certification:
LED Module Applications:
